Appendix A
Menu Trees
The menu trees on the following pages are a graphical representation of the hierarchy of the built-in
menu system of the IOLINK-520 & IOLINK-PRO. Each of the menus are shown with the
options of the menus being displayed below the specific menu name.
Each of the menu options shown in each of the menu trees is explained in the accompanying
IOLINK-520 & IOLINK-PRO VPN Menus Manual located on the accompanying CD-ROM.
Menu names are displayed in boxes. The numbers on the left side of the boxes indicate the menu
option from the parent menu that this menu corresponds to. All menu options are listed with
numbers indicating their actual position within the menu system.
Menu options contained within a grayed box are ISDN options. Menu options contained within a
black box are Frame Relay options.
IOLINK-520 & IOLINK-PRO Installation & Applications Guide — A. 1
