- Page 1 16/32 Channel 1U Rack Mount CCTV Power Supply Manual PH-A3224-GUQ Shown 16-Channel 32-Channel PH-A1612-PUQ PH-A3224-PUQ PH-A1612-GUQ PH-A3224-GUQ Glass Fuse Easy cable management Industrial design 12 Amp at 24VAC Dual-color LED status indicators 3 Amps per channel For rack mounting, wall mounting, and stacking Field-selectable 24/28 VAC Note: Model number that end with “Q”...
- Page 2 ENFORCER RACKMOUNT POWER SUPPLY Table of Contents: Introduction ............Sample Application ..........Features.............. Overview ............. Installation Notes ..........Troubleshooting ..........Parts List ............. Also Available ............. Specifications............Safety Warnings..........Installation............3- Warranty ............. Introduction: ENFORCER PH-A Series Rack Mount CCTV Power Supplies are the ideal way to simplify and consolidate your CCTV power supply system into one convenient package.
-
Page 3: Parts List
ENFORCER RACKMOUNT POWER SUPPLY Parts List: Rack mount power supply ......................1x Cable management brackets ...................... 2x Cable management hooks ......................2x M3x6 Cable bracket screws ......................4x Mounting brackets: ..................2x 16-channel models (rack/wall/surface mount) ................4x 32-channel models (wall and surface mount only) Extra-long rack mount brackets .............. - Page 4 ENFORCER RACKMOUNT POWER SUPPLY A2. Wall mounting (For 32-channel, see A4) Figure 1 Middle mounting point Bracket facing down 1. Remove the mounting screws from the middle mounting points as shown in Figure 1. 2. Screw the left and right mounting brackets on, Mounting bracket facing downward as shown in Figure 1.
- Page 5 ENFORCER RACKMOUNT POWER SUPPLY B. Wiring 1. Unplug terminal blocks from their sockets for easy installation. 2. Connect equipment power input cables to the screw terminals side by side in N/P pairs. 3. Screw the terminals closed. Once done, reinsert the terminal block back into its slot. 4.
- Page 6 ENFORCER RACKMOUNT POWER SUPPLY E1. Locking Tab, front position Figure 6 1. Install the front panel lock tab using the screw from the power Front panel supply front mounting point as Mounting bracket shown in Figure 6 to the right. Front panel lock tab 2.
- Page 7 ENFORCER RACKMOUNT POWER SUPPLY Sample Application: Figure 9 DC Cameras, Accessories, etc. Rack Mount Power Supply Use ENFORCER Voltage Converters to supply your DC ST-LA110-TTQ equipment ENFORCER Voltage Convertor Overview: A: Front mounting point Figure 10 Mounting brackets Power supply front panel B: Center mounting point Rubber foot &...
-
Page 8: Troubleshooting
ENFORCER RACKMOUNT POWER SUPPLY Troubleshooting: Power does not turn on Check front panel LEDs and rear main fuse. Ensure the power cord is firmly in its socket. Power cycles on and off The unit may be overheating. Check for heat sources nearby and ensure ventilation holes are free from obstruction.
