ENFORCER EB-P501-01Q Installation Manual

Installation Manual
Passive Video Baluns
Standard Baluns
EB-P501-01Q
• Standard
EB-P501-01SQ
• With surge protection
Power or Data Pass-Through
EB-P501-02Q
• Standard
EB-P501-02SQ*
• With surge protection
6" Pigtail and
Power or Data Pass-Through
EB-P501-21Q*
• Standard
EB-P501-21SQ*
• With surge protection
• Gold-plated BNC connector
• Transmits up to 1,300ft (400m) color video
• Passive operation – No external power required
• Uses low-cost Cat5e/6 cable instead of costly coaxial cable
• Terminal blocks – No crimping required**
• High immunity from interference
• Small size allows mounting of multiple baluns behind a DVR
* Special order item. Please contact SECO-LARM.
**EB-P501-22Q and EB-P501-23Q use RJ45 connectors.
Note: Products with model numbers that end with "Q" or that have a round green "Q" sticker are RoHS compliant.
6" Pigtail
EB-P501-20Q
• Standard
EB-P501-20SQ*
• With surge protection
RJ45
and DC Plug
EB-P501-22Q*
• Video/Power (Red DC plug)
EB-P501-23Q*
• Video/Power/Data
(Black DC plug)
