ENFORCER ST-Series Manual

ENFORCER Power Supplies/Chargers
Also Available from SECO-LARM
12VDC High-Amp
Switching CCTV Relay Boards
Power Supplies
PS-U1812-PULQ shown SR-2212-C5AQ shown
12VDC Plug-In
Power Converters
AC Adapters
ST-UV12-S1.0Q shown ST-LA130-TTQ shown

Troubleshooting:

• Check whether the AC input voltage or backup battery voltage is
No DC output
normal
• Check whether the output voltage setting is correct
• Check whether the AC input wattage is correct (see chart, pg. 3)
Low DC voltage output
• If the battery is supplying power, check whether the battery
voltage is normal
• Check whether the power supply board is overloaded
• Check whether the battery voltage is normal or already discharged
No backup battery power
• Check whether the master fuse has burned out
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for 1 (one) year from the date of sale to the original customer. SECO-LARM's obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if
damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment
is not operating properly as a result of causes other than defects in material and workmanship. The sole obligation of
SECO-LARM and the purchaser's exclusive remedy, shall be limited to the replacement or repair only, at SECO-LARM's
option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or property
damage of any kind to the purchaser or anyone else.
NOTICE: The SECO-LARM policy is one of continual development and improvement. For that reason, SECO-LARM
reserves the right to change specifications without notice. SECO-LARM is also not responsible for misprints.
Copyright © 2016 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or
in part, without the written permission of SECO-LARM.
®
SECO-LARM U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Phone: (949) 261-2999 | (800) 662-0800
4
® :
Low Battery Cutoff Timers
ST-BD01Q SA-025EQ shown
Plug-and-Play Open-Frame
Backup Batteries Transformers
SB-L10V1-20Q shown ST-UVDA-W180Q shown
Website: www.seco-larm.com
Email: sales@seco-larm.com
MI_ST-xx06-xxQ_160503.docx
SECO-LARM U.S.A., Inc.

Features:

• Automatic recharging of backup batteries
• Automatic switchover to backup battery if
main power is lost or cut
• Built-in battery short-circuit protection
• LEDs indicate power status
• High efficiency at full load
• Heat sink free design (except for
ST-2406-7AQ and ST-2406-10AQ)
®
PITSW1
763-074-11%
ST-Series
Power Supplies/Chargers
Manual
ST-2406-3AQ shown
• Programmable DC voltage output
• Regulated and filtered output voltage
• Fused output for a regulated charge
• Includes foam tape and battery leads
for easy installation
• Low-battery cutoff (ST-2406-2AQ,
ST-2406-3AQ, and ST-2406-5AQ)
