ENFORCER PS-U0406-PULQ Manual

ENFORCER DC Switching CCTV Power Supply
7. If voltage drop is large, adjust the output
voltage trimpot as shown in Figure 7.
NOTE / REMARQUE: The output voltage
trimpot changes voltage for all outputs.
Test all outputs to ensure voltage does not
exceed device specifications. Le
potentiomètre de tension des sorties
change la tension de toutes les sorties.
Vérifiez toutes les sorties pour assurer que
la tension ne dépasse pas les
spécifications de l'appareil.
