Grill Assembly - Frigidaire Electric Patio Grill Use & Care Manual

30" stainless steel outdoor grill with electric ignition

Advertisement

Table of Contents
Note: Prior to assembly remove protective film from stainless steel parts
Assembly requires: 4 tools and a Friend
Tools required:
Power screwdriver
Screwdriver extension
1/4" socket wrench
1/2" socket wrench
adjustable wrench
scissors
Caution: Gas regulator is not flush with
bottom. DO NOT let the Grill head sit flat
without placing support around regulator
to prevent damage to the regulator prior
to installing on cart.
Cart Assembly, Door Stops & Door Pivot Bolts
1.
Attach the two L-shaped sides to the back portion
of the cart, making sure the two holes face up &
the key holes are on the top, using the (4) self
tapping hex head screws. (See Fig. 1)
Note: A power screwdriver is required to install the
screws-be cautious not to over-tighten and strip
the screws.
2.
Set the base on the top of the cart assembly, with
large opening closer to back portion of cart, and
align the eight mounting holes. Then set the 2
wheel channels on the base and attach them using
the (8) bolts provided, from inside the cart
upwards through wheel channels. (See Fig. 2)
Note: Tighten the bolts securely
3.
Door Stop: Insert Door Stop Bolt downward
from bottom side of Cart Base through the hole
found in the right/front of the base. (See Fig 3)
4.
Screw Rubber Cap onto Bolt from the topside of
Cart Base and tighten securely. (See Fig 4)
4.
Door Pivot Bolt: Insert Bolt downward from
bottom side of Cart Base through the hole found
in the left/front of the base and secure with
bolt. (See Fig. 2)

Grill Assembly

5
Screws
Wheel Channel
Door Pivot
Bolt Hole
LP Tank
cutout
Bolt up through
bottom of cart base
Fig. 1
Door Stop
Fig. 2
Hole
Fig. 3
Fig. 4
