Defining elements
Group particles properties
General properties
Items list
54
To display a group particle property sheet, double-click its symbol in a
diagram.
The General page of a group particle property sheet displays the following
properties:
Property
Description
Type
Type of the group particle. You can change its type by selecting a
value in the dropdown listbox and clicking OK
Minimum
Minimum number of times the group particle can occur. To
specify that the group particle is optional, set this property to zero
Maximum
Maximum number of times the group particle can occur. For an
unlimited number of times, select unbounded
ID
ID of the group particle. Its value must be of type ID and unique
within the model containing the group particle
The Items page of a group particle property sheet allows you to add (or
order) the following objects to a list of child objects:
Tool
Tooltip
Add Element
Add Any
Add Group
Particle
Add Element
with Reference
to Element
Add Group with
Reference to
Group
When you add an object to the list, an object is created and its symbol
appears in the diagram linked to the group particle.
Description
Adds an element to the list
Adds an Any to the list. Only available with a
choice or a sequence group particle
Adds a group particle to the list
Adds a referencing element to the list. Select a
global element for the reference in the Selection
dialog box. To use this tool, you must have
previously defined a global element in the current
model
Adds a referencing group to the list. Select a group
for the reference in the Selection dialog box. To use
this tool, you must have previously defined a group
in the current model
