Tool Object
— Notation
These tools are available in the palette of the diagram window.
The main objects of an XML model are represented by symbols in its
diagram.
Objects in a diagram
Some objects may not appear in a diagram because they do not have a
symbol or this symbol has been deleted or hidden.
Always check the existence of objects in the Browser tree view.
Example of an XML diagram:
You can use several diagrams to have partial views of a complex diagram.
Chapter 1
Description
A notation is used to define and process non-
XML objects within an XML model
