XML Model objects verified by Check Model
Group particle check
Existence of particle
Invalid cardinality
XSM User's Guide
The Check Model verifies the validity of XML model objects.
When errors are encountered during a check model, corrections can be made
manually or automatically. Manual corrections depend on how you are using
your model.
Some checks are not available if the object is not supported in the model.
Use the Help command to select object control options
When you right click an XML model object control in the Check Model
Parameters page, a menu appears listing several options. The Help
command opens a contextual help page explaining the checks performed
for the selected object type.
During a group particle check, the following object control is made.
A group particle must contain elements, groups, group particles and/or Any.
Manual correction
Add items to the group particle or delete
it
You should define a minimum (0 or 1) and a maximum cardinality (1 or
unbounded) for a group particle occurrence.
This check is only available in a model targeted with XDR.
Manual correction
Double-click the group particle symbol
and type a value for Minimum (0 or 1)
and Maximum (1 or unbounded)
properties
Chapter 3
Working with an XML model
Automatic correction
—
Automatic correction
—
147
