Sybase PowerDesigner XML User Manual page 63

Adding an attribute to an element
XSM User's Guide
Element values with XDR
In a model targeted with the XML-Data Reduced language, there is also a
Values page in the element property sheet.
To add an attribute to an element:
1 Double-click the element symbol in the diagram.
The element property sheet appears.
2 Click the Attributes tab to display the Attributes page.
3 Click the Add Attribute tool to add an attribute to the list.
or
Click an empty row in the list.
4 Type a name and a code for the attribute.
5 Click OK.
Chapter 2 Building an XML model
51
