Defining an XML model
26
6 <optional> If you want to attach one or more extended model definitions
to the model, click the Extended Model Definitions tab, and select the
extended model definitions of your choice.
For more information on attaching extended model definitions to a
model, see section Selecting extended model definitions at model
creation.
7 Click OK.
A new XML model is created in the Workspace.
8 Select Model Model Properties.
or
Right-click any empty space in the diagram window and select
Properties from the contextual menu.
The model property sheet appears.
9 Type a name and a code for the model.
10 Click OK.
