XSM User's Guide
Chapter 5
Exchanging data with databases supporting XML
11 In the XML in Database page, select Microsoft SQL Server.
Note: In the General Purpose page, you can select the XML Document
extended model definition to generate a simplified XML file that will
help you understand the annotated schema.
12 Click OK.
Microsoft SQL Server appears in the List of Extended Model
Definitions.
13 Click OK.
The Microsoft SQL Server extended model definition appears in the
Browser tree view, attached to the generated XML model.
Annotated schema preview
By clicking the Preview page of the model property sheet, you can
have a preview of the annotated schema.
14 Select Language Generate XML Schema Definition File.
or
Select Language Generate XML-Data Reduced File.
223
