Generating an XML model from an Object-Oriented Model

Generating a new XML model from an OOM

192
You can generate an XML model from an OOM or from a package in an
OOM. PowerDesigner creates a new XML model containing all the objects
that you selected to generate in the XML model. The newly created XML
model appears in the browser and the corresponding diagram opens in the
work area.
You can only generate an XML model from the active OOM diagram.
To generate a new XML model from an OOM:
1 Select Tools Generate XML Model to display the XML Model
Generation Options dialog box.
2 Select Generate new XML Model radio button.
3 Type a name and a code for the new XML model, otherwise it will have
the same name and code as the OOM.
4 <optional> Click Configure Model Options to define the options of the
generated XML model.
