INHIBIT OPTION

P7 Connecting Block
26 W/BL T
1 BL/W R
37 BK/O Inh.
12 O/BK Inh.
EXTERNAL TONE SOURCE USING A V-9927A
P7 Connecting Block
Control
from time
clock
31
Emergency 33
Closure
Normally
Open Switch
*NOTE: External tone source requires dip switch settings to enable
feature. See Table 1(SW3-8)

SMDR PRINTER PORT CABLE

DB9 Female
To P10
V-2924A
Control
Unit
Baud Rate 9600, 8 bit, no parity, 1 stop bit
Tel.Sys. C.O. Line
position or single
line telephone
Dedicated "Meet
Me" Telephone
T R A A1
5.1K Ohm
W/S 30
S/W 5
6
R/O 32
O/R 7
8
R/BR
34
BR/R
9
DB25 Male
2 2
3 3
5 7
8
V-9927A
Signal
Out
(1-8)
Com
