FIGURE 2 - PUNCHDOWN BLOCK CONNECTIONS
Block P3 - Speaker Outputs
26 W/BL T STA 1
1 BL/W R STA 1
27 W/O T STA 2
2 O/W R STA 2
28 W/GR T STA 3
3 GR/W R STA 3
29 W/BR T STA 4
4 BR/W R STA 4
30 W/S T STA 5
5 S/W R STA 5
31 R/BL T STA 6
6 BL/R R STA 6
32 R/O T STA 7
7 O/R R STA 7
33 R/G T STA 8
8 G/R R STA 8
34 R/BR T STA 9
9 BR/R R STA 9
35 R/S T STA 10
10 S/R R STA 10
36 BK/BL T STA 11
11 BL/BK R STA 11
37 BK/O T STA 12
12 O/BK R STA 12
38 BK/G T STA 13
13 G/BK R STA 13
39 BK/BR T STA 14
14 BR/BK R STA 14
40 BK/S T STA 15
15 S/BK R STA 15
41 Y/BL T STA 16
16 BL/Y R STA 16
42 Y/O T STA 17
17 O/Y R STA 17
43 Y/G T STA 18
18 G/Y R STA 18
44 Y/BR T STA 19
19 BR/Y R STA 19
45 Y/S T STA 20
20 S/Y R STA 20
46 V/BL T STA 21
21 BL/V R STA 21
47 V/O T STA 22
22 O/V R STA 22
48 V/G T STA 23
23 G/V R STA 23
49 V/BR T STA 24
24 BR/V R STA 24
50 V/S N. C.
25 S/V N. C.
Block P6 - Switch Inputs
26 W/BL INA1
1 BL/W INB1
27 W/O INA2
2 O/W INB2
28 W/GR INA3
3 GR/W INB3
29 W/BR INA4
4 BR/W INB4
30 W/S INA5
5 S/W INB5
31 R/BL INA6
6 BL/R INB6
32 R/O INA7
7 O/R INB7
33 R/G INA8
8 G/R INB8
34 R/BR INA9
9 BR/R INB9
35 R/S INA10
10 S/R INB10
36 BK/BL INA11
11 BL/BK INB11
37 BK/O INA12
12 O/BK INB12
38 BK/G INA13
13 G/BK INB13
39 BK/BR INA14
14 BR/BK INB14
40 BK/S INA15
15 S/BK INB15
41 Y/BL INA16
16 BL/Y INB16
42 Y/O INA17
INB17
17 O/Y
43 Y/G INA18
18 G/Y INB18
44 Y/BR INA19
19 BR/Y INB19
45 Y/S INA20
20 S/Y INB20
46 V/BL INA21
21 BL/V INB21
47
V/O INA22
22 O/V INB22
48 V/G INA23
23 G/V INB23
49 V/BR INA24
24 BR/V INB24
50 V/S N. C.
25 S/V N. C.
6
Block P7 - System Inputs
26 W/BL Tip - Attendant Tel
1 BL/W Ring - Attendant Tel
27 W/O Common Audible C.C.
2 O/W Common Audible C.C.
28 W/GR BGM Input
3 GR/W BGM Input
29 W/BR Riot Mode
4 BR/W Riot Mode
30 W/S External Tone - Tip
5 S/W External Tone - Ring
31 R/BL Clock Activate
6 BL/R Clock Activate
32 R/O Clock Enable C. C.
7 O/R Clock Enable C. C.
33
R/G Emergency Activate
8 G/R Emergency Activate
34 R/BR Emergency Enable C. C.
9 BR/R Emergency Enable C. C.
35 R/S Override Page Port - Tip
10 S/R Override Page Port - Ring
36 BK/BL Dry Priority Activate
11 BL/BK Dry Priority Activate
37 BK/O Inhibit
12 O/BK Inhibit GND
38 BK/G N. C.
13 G/BK N. C.
39 BK/BR N. C.
14 BR/BK N. C.
40 BK/S N. C.
15 S/BK N. C.
41 Y/BL N. C.
16 BL/Y N. C.
42 Y/O Global Priority Activate
17 O/Y Global Priority Activate
43 Y/G Global All Call Activate
18 G/Y Global All Call Activate
44 Y/BR Global Page Tip
19 BR/Y Global Page Ring
45 Y/S Clock Sync
20 S/Y Clock Sync
46 V/BL Night Ring Activate
21 BL/V Night Ring Activate
47 V/O Sta. 21 C. C.
22 O/V Sta. 21 C. C.
48 V/G Sta. 22 C. C.
23 G/V Sta. 22 C. C.
49 V/BR Sta. 23 C. C.
24 BR/V Sta. 23 C. C.
50 V/S Sta. 24 C. C.
25 S/V Sta. 24 C. C.
