ZONE PAGE OPTION

ONE WAY ONLY
P3 Speaker Outputs
TSTA1 26
RSTA1 1
TSTA2 27
RSTA2 2
TSTA3 28
RSTA3 3
P6 Switch Inputs
INA1 26
1
INB1
27
INA2
2
INB2
28
INA3
INB3 3
CLOCK SYNC INPUT
P7 Connecting Block
Y/S 45
S/Y 20
Master Clock must make contact closure at 0200 Hours.
V-1092
* To Enable Feature, strap must remain
across pair when unit is powered
10
70 Volt
Amp
Master
Clock
