P7 Connecting Block
EXTERNAL TONE SOURCE USING A V-9927A
Emergency
Closure
Normally
Open Switch
NOTE: External tone source requires dip switch settings to enable
feature. See Table 1(SW3-8)
947211_2.DRW

INHIBIT OPTION

26 W/BL T
1 BL/W R
37 B / O Inh.
12 O / B Inh.
P7 Connecting Block
Control
from time
clock
31
6
33
8

SMDR PRINTER PORT CABLE

DB9 Female
To P10
V-2924
Control
Unit
Baud Rate 9600, 8 bit, no parity, 1 stop bit
8
Tel.Sys. C.O. Line
position or single
line telephone
Dedicated Meet
Me Telephone
T R A A1
5.1 Ohm
W/SL 30
SL/W 5
R/O 32 Signal
O/R 7
Out
(1-8)
R/BR
34
Com
BR/R
9
DB25 Male
2 2
3 3
5 7
V-9927A
947211
