eplacement parts
Item Part No.
1 203-8107
2 203-8108
3 203-8109
4 203-6675
5 203-6676
6 203-6677
7 203-8111
8 203-6679
9 203-6845
10 203-6680
11 203-6682
12 203-6685
13 203-6686
14 203-6688
15 203-6804
16 203-6689
17 203-6690
18 203-8112
1 2
6 7
11 12
16 17
w w w . b i s s e l l . c o m
Part Name
Tank Assembly (complete)
Tank Lid
Tank Bottom
Cap and Insert for Water Tank
Formula Tank (includes Cap & Insert for Formula Tank)
Cap and Insert for Formula Tank
Front Nozzle (includes gasket)
Autoload Gasket (fits both Water and Formula Tank)
Float Door
Tank Filter (Lint Screen)
Cord Wrap (Black)
Clear End Cap w/Edge Brushes (2 pack, includes screws)
Brush Roll – 6 row (includes 1 brush, axle, 2 swivel arms)
Small Brush Belt (non-cord side)
Large Brush Belt (cord side)
Hose Secure Latch
Hose Rack Assembly (Top/Bottom Hose Rack, Screws)
CleanShot Cover
