R E V O L U T I O N
U S E R ' S G U I D E
3760/4220/6850/6860 SERIES
3
4
4-6
6-9
10-13
Maintenance
14
Troubleshooting
15
Replacement Parts
15
Consumer Services
®
Lift-Off
Safety Instructions
Product Diagram
Assembly Instructions
Operation / Special Tools
™
10/3/05 3:52:43 PM
10/3/05 3:52:43 PM
Advertisement
Table of Contents
Related Manuals for Bissell 4220 Series
Summary of Contents for Bissell 4220 Series
- Page 1 Consumer Services Warranty ug603-5567_3760-6850_905.indd 1 ug603-5567_3760-6850_905.indd 1 ® Lift-Off R E V O L U T I O N U S E R ’ S G U I D E 3760/4220/6850/6860 SERIES Safety Instructions Product Diagram Assembly Instructions Operation / Special Tools 10-13 Maintenance Troubleshooting...
- Page 2 Your BISSELL Vacuum is well made, and we back it with a limited comprehensive one-year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
-
Page 3: Important Safety Instructions
■ Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. ■ Do not handle vacuum cleaner or plug with wet hands. ■ Do not put any object into openings. Do not use with any opening blocked; keep openings free of dust, lint, hair, and anything that may reduce air flow. - Page 4 Dusting Brush/ Upholstery Tool Hose Clip Upper Tank Knob Twist n' Snap Hose Connection Crevice Tool HEPA Media Post-Motor Filter Handle Release Pedal Hose Grip Base Height Adjustment Knob Powerfoot CAUTION: Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures.
-
Page 5: How To Use This Guide
How To Use This Guide This User’s Guide has been designed to help you get the most satisfaction from your BISSELL Vacuum. You’ll find assembly and operating instructions, safety precautions, as well as maintenance and troubleshooting instructions. Please read this Guide thoroughly before assembling your vacuum cleaner. -
Page 6: Handle Positions
You may want to turn the Brush Switch “OFF” (O) for bare floor cleaning or other delicate surfaces. Note: Your BISSELL Lift-Off Revolution vacuum is equipped with a special internal switch that turns the Rotating Brush off whenever the unit is in the Upright position. -
Page 7: Special Tools
Cleaning Position. Special Tools Your vacuum is not only a powerful floor vacuum cleaner, it’s also a versatile stairs and above floor vacuum when you select one of the special tools. Note: The tools can be used with the vacuum in the Upright Position or with the Detachable Canister. - Page 8 Cleaning With The Detachable Canister The Detachable Canister feature makes it possible to easily take the powerful cleaning action of your BISSELL Lift-Off Revolution to stairways, auto interiors, and other hard-to-reach areas of your home. Before detaching the Canister, your vacuum must be in its fully Upright Position.
-
Page 9: Shoulder Strap
Canister. Clip molded plug to Power Cord to secure. Transporting Cleaner To move your vacuum cleaner from room to room, put the Handle in the Upright Position, tilt the cleaner back on its rear wheels and push forward. The cleaner can also be moved by using the Carrying Handle on the Detachable Canister. - Page 10 How to Maintain Your Vacuum To maintain maximum cleaning performance, the following maintenance steps must be performed: Empty the Dirt Container when the dirt reaches the “Full” line on the front. Check the Upper Tank and Pre-Motor Filters at least once a month and clean and replace as needed.
- Page 11 Unplug cleaner from electrical outlet. Remove Detachable Canister from vacuum cleaner. Recline Handle and turn vacuum cleaner over so bottom side is up. Remove the six screws as shown with a Phillips head screwdriver. Lift the Brush Cover off.
-
Page 12: Replace Light Bulb
Rotating Brush and Drive Belt Maintenance Continued Place one end of the new Drive Belt over Motor Pulley and the other end over the Brush in the space between the bristles. Pull the Brush firmly to stretch the Drive Belt and place ends of Brush down into slots on sides as shown. -
Page 13: Clearing Clogs
If the thermal protector continues to activate after following the above steps, your cleaner may need servicing. Call BISSELL Consumer Services, or visit the website. Note: The thermal protector controls the main vacuum motor only, not the brush motor. If the thermal protector activates, the brush will continue to operate normally;... -
Page 14: Troubleshooting
No Power at Rotating Floor Brush Possible Causes Canister is not securely seated Brush Switch turned to “Off” Vacuum is in upright position Vacuum cleaner won’t pick up dirt Possible Causes Incorrect Height Adjustment Hose not attached to suction opening Crack or hole in Hose... -
Page 15: Replacement Parts
Replacement Parts – BISSELL Lift-Off Revolution Series You may purchase replacement parts from your retailer, by calling BISSELL Consumer Services or by visiting our website. To locate a retailer near you, or to place an order using Visa, MasterCard, Discover... -
Page 16: Limited One Year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, upon receipt of the product BISSELL Homecare, Inc. will repair or replace (with new or remanufactured components or products), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for one year any defective or malfunctioning part.
