How To Operate The Receiver - Beyerdynamic Stegos Operating Instructions Manual

Stegos – RS Receiver
Wiring Phoenix terminal strips – rear view Stegos RS
2.5

How to operate the receiver

• Turn on the receiver with the on/off switch
on LED will illuminate.
• The channel LEDs 1 to 4 will illuminate green to indicate the
availability. As soon as you turn on the first Stegos TB boundary
microphone, the channel LED 1 will illuminate
that the channel is occupied.
• At the factory the RF band "Low" has been adjusted. If inter-
ferences occur, you should change the frequency band. Use the
tip of a pencil or a paper clip to press the countersunk push-
button for RF band selection
automatically set to the selected frequency band.
. The green power
red to indicate
. The boundary microphones are
9
Shield
+
Hot
-
Cold
