10
2.6

How to install a receiver into a 19" rack

• If you want to install a receiver into a 19" rack, mount the supplied brackets to the right and left
hand side.
Mounting bracket
3.

Stegos TB boundary microphone

The boundary microphone provides a semi-cardioid polar pattern with a high gain before feedback. The
microphone is powered via integrated rechargeable NiMH batteries, which have to be recharged before
using the microphone the first time. The operating time is 14 hours at minimum. The microphone can
be recharged or operated permanently via a power supply unit connected to the DC connection. The
maximum charging time is around 2 hours. The battery and charging state is displayed via an LED on the
rear of the microphone.
3.1

Controls and indicators

Button for On / Off / Mute of the microphone
DC connection for charging or DC-powered operation
Operating control LED
Button for On / Off of the device
Stegos – TB Boundary Microphone
Mounting bracket
