Using an External Antenna with the Access Point 530

External Antenna Options

External Antenna Options
The Access Point 530 external antenna options are outlined in the following
table:
Table 4-1.
Antenna Type
2.4 GHz 5 dBi indoor/outdoor
omnidirectional
2.4 GHz 8 dBi outdoor
omnidirectional
2.4 GHz 14 dBi indoor/outdoor Yagi
(for point-to-point operation)
2.4 / 5 GHz 3 dBi indoor
omnidirectional diversity
5 GHz 6 dBi indoor/outdoor
omnidirectional
2.4 / 5 GHz 7 dBi indoor/outdoor
directional
5 GHz 14 dBi indoor/outdoor
directional (for point-to-multipoint
operation)
4-2
Summary of External Antennas to Use With the Access Point 530
Part Number Mounting
J8441A Ceiling or mast
J8444A Mast
J8448B Articulating wall or
mast mount
J8997A Ceiling grid
J8998A Ceiling, mast or
I-beam
J8999A Flush wall mount with
integrated
articulating feature
J9000A Flush wall mount with
integrated
articulating feature
Horizontal Vertical
Beamwidth (3dB) Beamwidth (3dB)
360 Degrees 31 Degrees
360 Degrees 12 Degrees
34 Degrees 30 Degrees
360 Degrees 70 Degrees
360 Degrees 17 Degrees
68 Degrees 66 Degrees
29 Degrees 27 Degrees
