Bacharach Flue-Gas Sample Conditioning System Instruction page 3

Figure 2. Equipment Setup
PELTIER
COOLER
4
PROBE ASSEMBLY
PUMP
POWER SUPPLY
Bacharach, Inc.
Flue Gas Sample Conditioning System
Connect to
Combustion Test
Equipment
STACK TEMP.
THERMOCOUPLE
PRESSURE (Blue)
FLUE GAS (Yellow)
100 – 240 VAC
50/60 HZ
Instruction 0024-9415
