Flue Gas Sample Conditioning System

Replacement Parts

Item
(Fig 3)
Instruction 0024-9415
Probe:
1 Complete Assembly (w/ 11.5 in. probe tube)............. 0024-3038
2 Probe Tubes:
7 in. (180 mm) ...................................................... 0024-1183
11.5 in. (295 mm) ................................................. 0024-1184
19.5 in. (500 mm) ................................................. 0024-1185
39 in. (1000 mm) .................................................. 0024-1186
3 Gas Hose Fitting ........................................................ 0024-0877
4 Draft Hose Fitting ...................................................... 0024-0878
5 Probe Stop .................................................................. 0019-3037
6 Thumb Screw ............................................................. 0102-0875
7 Screw, M4 x 6mm ....................................................... 0501-3829
8 Retaining Nut ............................................................. 0102-3740
9 Filter (Qty. 5).............................................................. 0007-1646
Peltier Cooler & Power Supply:
10 Complete Assembly, Peltier Cooler & Power
Supply (AC Power Cord not included) ................... 0024-1179
11 Plastic End Cap .......................................................... 0106-5454
12 Filter Wadding ........................................................... 0007-1647
13 Power Supply ............................................................. 0304-1713
14 AC Power Supply Cord, 3-Wire ................................. 4998-8986
Condensate Pump:
15 Complete Assembly .................................................... 0024-1180
16 Reservoir .................................................................... 0106-5453
17 Plastic Screw-On Cap ................................................ 0106-5455
18 Filter Wadding (Qty. 1) .............................................. 0024-1205
19 Plastic Cap w/ Drain .................................................. 0106-5456
O-Rings:
20 9 x 2 mm ..................................................................... 0105-5105
21 4 x 1.75 mm ................................................................ 0105-5106
22 50 x 3 mm ................................................................... 0105-5107
23 11 x 1 mm ................................................................... 0105-5108
Bacharach, Inc.
Description Part No.
7
