Flue Gas Sample Conditioning System

Technical Data

Probe:
Peltier Cooler:
Condensate Pump:
Power Supply:

Equipment Setup

Refer to Figure 2. If not already done, attach the Peltier cooler to the
probe as sem bly by fi rst removing the plastic end cap from the rear of
the probe, and then inserting the cooler's inlet connector, en sur ing fi rst
that a fi lter is present between the cooler and probe.
Attach the pump's inlet hose to the bottom of the Peltier cooler. Water
that is condensed from the fl ue-gas sample will be pumped into the con-
densate pump's reservoir through this hose. Note that the con den sate
pump can be placed in an upright, horizontal, or hanging po si tion. A
mag net mounted in the base of the pump allows the pump to be at-
tached to overhead ductwork.
Connect the power supply's DC output connector to the con den sate
pump; then connect the condensate pump's DC output power con nec tor
to the Peltier cooler. The Peltier cooler and its associated con den sate
pump are started by plugging the power supply into a source of AC
power that is be tween 100 and 240 VAC, 50/60 Hz.
Connect the probe assembly's stack-temperature thermocouple con-
nec tor, pres sure fi tting, and fl ue-gas fi tting to the combustion an a lyz er
per the analyzer's instruction manual.
Instruction 0024-9415
Standard Length ......................................................... 11.5 in (295 mm)
Optional Lengths ............................................................. 7 in (180 mm)
Inlet Sample Dew Point.......................................... 149 °F (65 °C) max.
Outlet Sample Dew Point .................18 °F (10 °C) min. below ambient
Cooling Power ................................................................................. 10 W
Environment Temperature ............................. 32 to 104 °F (0 to 40 °C)
Weight ................................................................................8.5 oz (240 g)
Sample Flow Rate ..........................................................1.5 LPM @ STP
Length of Hose ...................................................................... 6.6 ft (2 m)
Reservoir Storage ........................................................................... 50 ml
Environment Temperature ............................. 32 to 104 °F (0 to 40 °C)
Weight ..............................................................................12.7 oz (360 g)
Input ..............................................................100 to 240 VAC, 50/60 Hz
Output ............................................................ 9 VDC, max. @ 4 A, max.
Bacharach, Inc.
19.5 in (500 mm)
39 in (1000 mm)
3
