8 | English

Noise/Vibration Information

Measured sound values determined according to 2000/14/EC (1.60 m
height, 1 m distance away).
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Wear hearing protection!
Vibration total values (triax vector sum) determined according to
EN 60335:
Vibration emission value a
Uncertainty K

Declaration of Conformity

We declare under our sole responsibility that the product described un-
der "Technical data" is in conformity with the following standards or
standardization documents: EN 60335, EN 50338 (battery powered
product) and EN 60335 (battery charger) according to the provisions of
the directives 2006/95/EC, 2004/108/EC, 2006/42/EC, 2000/14/EC.
2000/14/EC: Guaranteed sound power level
Conformity assessment procedure according to Annex VI.
Equipment category: 32
Notified body:
SRL, Sudbury, England, Nr. 1088
Technical file at:
Bosch Lawn and Garden Ltd., PT-LG/EAE,
Stowmarket, Suffolk IP14 1EY, England
08
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
14.09.2010

Mounting and Operation

Action
Delivery Scope
Handle Assembly
Snap together the Grassbox
Grassbox fitting/removing

Battery Charging

Inserting/Removing the Battery
Remove Isolator Key and fit in the Storage
Position
Adjusting the Cutting Height
Starting
Stopping
Working Advice
Blade Maintenance
Selecting Accessories
Starting

For Your Safety

Warning! Switch off, remove the isolator key and
the battery before adjusting, cleaning or if cable
is cut, damaged or entangled.
The blades continue to rotate for a few seconds
after the machine is switched off.
Caution
do not touch the rotating blade.
Battery Charging
Do not use other battery chargers. The supplied
battery charger is designed for the Lithium-Ion bat-
tery in your garden product.
Observe the mains voltage! The voltage of the
power supply must correspond with the data given
on the nameplate of the battery charger. Battery
chargers marked with 230 V can also be operated
with 220 V.
F 016 L70 762 | (27.9.10)
h
Dr. Eckerhard Strötgen
Head of Product
Certification
Figure
1
2
3
4
5
6
7
8
9
9
9
10
11
12
3 600 ...
dB(A)
dB(A)
dB
2
m/s
2
m/s
3 600 ...
dB(A)
The battery is equipped with temperature monitoring
that allows charging only in the temperature range be-
tween 0 °C and 45 °C. In this manner, a high battery
service life is achieved.
Note: The battery is supplied partially charged. To en-
sure full capacity of the battery, completely charge the
battery in the battery charger before using your power
tool for the first time.
The lithium ion battery can be charged at any time
without reducing its service life. Interrupting the
charging procedure does not damage the battery.
The "Electronic Cell Protection (ECP)" protects the
lithium ion battery against deep discharging. When the
battery is run down or discharged, the garden product
is shut off by means of a protective circuit: The blade
no longer moves.
Do not continue to press the
WARNING
On/Off switch after the garden
product has been automatically switched off. The
battery can be damaged.
Charging Procedure
The charging procedure starts as soon as the mains
plug of the battery charger is plugged into the socket
outlet and the battery is inserted into the charging
compartment.
Due to the intelligent charging method, the charging
condition of the battery is automatically detected and
the battery is charged with the optimum charging cur-
rent, depending on battery temperature and voltage.
This gives longer life to the battery and always leaves
it fully charged when kept in the charger for storage.
Rapid-charging Procedure
AL 3640 CV
Professional
AL 3620 CV
Professional
The rapid-charging procedure is indicated by flashing
of the green charge control LED.
Indication element of the battery: During the charging
procedure, the three green LEDs light up one after the
other and briefly go out. The battery is fully charged
when the three green LEDs light up continuously. The
three LEDs go out again approx. 5 minutes after the
battery has been fully charged.
Note: The rapid-charging procedure is only possible when
the battery temperature is within the allowable charging
temperature range, see section "Technical Data".
Battery Charged
AL 3640 CV
Professional
AL 3620 CV
Professional
H81 E..
H81 J..
H81 K..
81.0
81.0
81.0
89.4
89.7
90.2
=0.6
=0.3
=0.8
<2.5
<2.5
<2.5
=1.5
=1.5
=1.5
H81 E..
H81 J..
H81 K..
90.0
90.0
91.0
Bosch Power Tools
