- Page 1 AW19FM & AW19FTH Morticers Axminster Reference No’s: AW19FM & AW19FTH 100255 (AW19FM) Floor Standing 600779 (AW19FTH) Morticer Floor Tilt Head A X M I N S T E R W H I T E Axminster Devon EX13 5PH UK Morticer...
-
Page 2: Table Of Contents
Illustration and Parts Description..................6,7,8,9 Installing the Chisel and Bit......................10 Operating Instructions......................11,12 Maintenance..........................13 Illustrated Parts Breakdown for AW19FM...................14 Illustrated Parts List for AW19FM....................15 Illustrated Parts List for AW19FM....................16 Illustrated Parts Breakdown for AW19FTH................. 17 Illustrated Parts List for AW19FTH....................18 Illustrated Parts List for AW19FTH.................... -
Page 3: What's In The Box
W H I T E Quantity Item Model Work Stop Assembly Numbers 1 No. Axminster AW19FM or AW19FTH Morticer MS3840, MS3840T 1 No. Cabinet Stand with Shelf and Lockable Drawer 4 No. M12 x 120 Hex Head Bolts and Washers 1 No. -
Page 4: Specific Safety Instructions For Morticers
Keep water and solvents away from all electrical components, leads and plugs. • When storing or leaving tools for any length of time, spray bare metal surfaces with Axminster XMP protective spray to minimise surface corrosion. -
Page 5: Unpacking And Assembly
Remove the morticer and stand from the shipping cartons. Report any shortages or damage W H I T E W H I T E to Axminster Power Tools Customer Services Department. (0800 371822) Read the manual thoroughly, familiarising yourself with the correct safety, operating and Cabinet Assembly maintenance procedures before proceeding further. -
Page 6: Illustration And Parts Description
Motor W H I T E W H I T E Fig A Operating handle Chuck access door Gas powered head return spring Workstop assembly Quick action hold down clamp Worktable gib strip adjusters Stand Base casting Traverse slide www.axminster.co.uk... - Page 7 Illustrated Parts List for AW19FTH... Illustration and Parts Description... A X M I N S T E R A X M I N S T E R NVR switch fitted to the W H I T E W H I T E AW19FTH morticer Fig B Grip sleeve...
- Page 8 A X M I N S T E R A X M I N S T E R W H I T E W H I T E Fig C Head depth stop Depth stop assembly Head casting Mortice depth stop Table length stop www.axminster.co.uk...
- Page 9 Illustrated Parts List for AW19FM... Illustration and Parts Description... A X M I N S T E R A X M I N S T E R W H I T E W H I T E Fig D Table length stops...
-
Page 10: Installing The Chisel And Bit
Installing the Chisel and Bit... Illustrated Parts List for AW19FM... A X M I N S T E R A X M I N S T E R W H I T E W H I T E 1. Select the size of mounting bush to suit the chisel being used and fit into the morticing head. -
Page 11: Operating Instructions
Illustrated Parts Breakdown for AW19FM... Operating Instructions... A X M I N S T E R A X M I N S T E R W H I T E W H I T E 1. Set the depth of the mortice with the lower of the two depth stops (Fig C) on page 8. - Page 12 (F) sign of excessive heat caused by a blunt auger and/or chisel. Bits are best sharpened with a small file and chisels with the special mortice chisel sharpeners available through Axminster Power Tool Centre (Tel 0800 371822). Burrs can be removed from the sides of the chisel on a fine oilstone or waterstone but great Fig 3 care must be taken not to taper the chisel as this will cause the chisel to jam in the timber.
