Woodturner's
Clubman &
Goliath Chucks
Users Manual
w w w. a x m i n s t e r. c o . u k

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Woodturner’s Clubman & Goliath Chucks and is the answer not in the manual?

Questions and answers

Summary of Contents for Axminster Woodturner’s Clubman & Goliath Chucks

  • Page 1 Woodturner’s Clubman & Goliath Chucks Users Manual w w w. a x m i n s t e r. c o . u k...
  • Page 2: Table Of Contents

    Right & Left Hand Threads Table................Back Cover Copyright... The Clubman & Goliath Chucks & Jaws has been wholly designed and manufactured by Axminster Power Tool Centre Ltd who have exclusive use of the design and manufacture. As such it should not be copied or reproduced.
  • Page 3: Introduction

    Apart from the Junior, which uses engineering end mill collets to hold small work pieces, all the Axminster chucks use the tried and tested scroll mechanism to control the jaw travel. This system provides the dual benefits of a nominal half inch of radial movement of each jaw in expansion and...
  • Page 4: Basic Safety For Machine Tools

    Basic Safety for Machine Tools... Good Working Practices/Safety The following suggestions will enable you to observe good working practices, keep yourself and fellow workers safe and maintain your tools and equipment in good working order. WARNING!! KEEP TOOLS AND EQUIPMENT OUT OF THE REACH OF YOUNG CHILDREN BASIC SAFETY FOR MACHINE TOOLS KNOW YOUR MACHINE TOOL Read and understand the owner's manual and labels affixed to the tool.
  • Page 5: Specific Safety Instructions For The Chuck

    Basic Safety for Machine Tools... DO NOT OVERREACH Keep proper footing and balance at all times. MAINTAIN TOOL WITH CARE Keep tools sharp and clean at all times for the best and safest performance. Follow the manufacturer's instructions for lubricating and sharpening and also for changing accessories. DISCONNECT POWER FROM THE TOOL Before servicing or when changing accessories always disconnect the power supply to avoid accidental starting.
  • Page 6: A Brief History

    (physical size) range of the mounting jaws, for use with the smaller chucks on the smaller lathes. The three new chucks are available with integral mounting threads T01 (3/4" x 16 t.p.i.) or T04M (1" x 8 t.p.i.). All 80mm jaws will fit all of the larger chucks in the Axminster range. Lathe Thread Information...
  • Page 7: Axminster Clubman Chucks

    Axminster Clubman Chucks... AXMINSTER CLUBMAN K8 80mm In response to a demand for a smaller chuck for smaller lathes we have brought out this brand new product, an 80mm diameter version of the familiar Woodturner’s Chuck. The Clubman K8 comes with mounting jaws fitted as standard with a key tightening system.
  • Page 8: Clubman K10 100Mm Chuck

    Axminster Clubman Chucks... AXMINSTER CLUBMAN K10 100mm This is the familiar Woodturner’s Chuck but now with a new name and a flashy new livery of nickel plated body and mounting jaws. There is a practical reason for the plating, not just to improve the appearance but to give greater protection against corrosion.
  • Page 9: Axminster Goliath 125Mm Chuck

    The chuck uses our well established, patented, accessory mounting jaws which are standard throughout the range of Axminster chucks allowing the full range of Axminster jaws to be used. Supplied with a long chuck key, the chuck has a bright nickel plated body and threaded boss (available in common 4 thread sizes).
  • Page 10: Axminster Junior Chuck

    Axminster Junior Chuck... AXMINSTER JUNIOR The Axminster Junior chuck is the first true collet chuck to be produced with woodturners specifically in mind. In this chuck we use our successful ER engineering collets which are precision machined to grip evenly along their whole length without marking the work.
  • Page 11: 100Mm Woodturning Chuck Jaws

    100mm Woodturning Chuck Jaws... DOVETAIL JAWS (DOVE A & B) The A dovetail jaws are designed to expand into a 100mm recess and compress on to both 60mm and 25mm spigots. The B dovetail jaws gives expansion into a 62mm recess and compression onto a 25mm spigot.
  • Page 12: 150Mm Colossus Gripper Jaws

    100mm Woodturning Chuck Jaws... AXMINSTER LARGE GRIPPER JAWS (DOVE G) Specially designed to give a massive grip, particularly 112mm on large diameter parallel 87mm pieces. The type G gripper jaws have a large dovetail 16mm 75˚ 25mm on the outside for turning...
  • Page 13: 80Mm Woodturning Chuck Jaws

    A convenient which to mount a bowl blank prior to turning. way of Availble to fit Axminster Dovetail Jaws only. mounting a Order no: 500169 screw chuck into the lathe without having to remove the chuck. This version has a stepped mounting plate which fits securely into the corresponding recess in the Dove C 80 Jaws.
  • Page 14: Woodturning Chuck Jaws Accessories

    DRIVE CENTRE (to suit DOVEC jaws) parallel screw mounted onto The Axminster four prong parallel drive centre has a boss which fits into either the 62mm been designed to be used in the central bore of the recess of the A dovetails or the internal recess of the C jaws fitted to the Carlton, Super Precision, C dovetail jaw.
  • Page 15: Mounting The Chuck To The Lathe

    Dovetail Jaws for small work. DOVE D (Order no: 410164). Axminster Mega Jaws. DOVE M (Order no: 410174). Axminster Gripper Jaws. DOVE H (Order no: 410170), DOVE BF (Order No: 410160). Axminster Internal & External Jaw Set. (Order no: 200038).
  • Page 16 Axminster Devon EX13 5PH UK FREEPHONE 0800 371822 www.axminster.co.uk...
