Cordless telephone

Figure 98: CALLMASTER V digital telephone
Figure notes
1 Dial pad
2 Display
Cordless telephone
MDC9000 cordless telephone
The MDC 9000 Cordless Telephone has two basic parts, the handset and the charging base.
•
The handset has line/programmable feature/intercom buttons, Conference, Drop, Hold, Transfer,
Status, and Feature buttons, Headset On/Off and Handset On/Off buttons, a LCD display, an
earpiece volume control switch, battery charging contacts, a directory card, and a headset jack.
•
The charging base has a handset hook, ringer volume controls, battery charging contacts, a Talk
indicator, a Charge indicator, a Message indicator, and a base ringer.
MDW9000 cordless telephone
The MDW 9000 Wireless Telephone is part of the TransTalk
telephones. This wireless telephone has three basic parts, the handset the charging cradle, and the radio
module.
•
The handset has line/programmable feature/intercom buttons, Drop, Mute, Hold, Conference, and
Transfer buttons, a Headset On/Off button and a Handset On/Off button, a LCD display, a Volume
control switch, battery charging contacts, a flexible antenna, and a Headset jack.
