Chapter 1 Overview and specifications
2
Agency listing/compliance
CE—Immunity: EN 50082-1:1997; EN 50082-2:1995
CE—Emissions: EN 50081-1:1992 (CISPR 22) Class B
UL and C-UL 916 listed: Energy management system
UL 94-5V (UL flammability rating for plenum use)
FCC Part 15, Class A
Dimensions
Plastic-cover model dimensions
For complete dimensional drawing, see Figure 1 on page 3.
Height: 5.375 in. (137 mm)
•
Width: 6.875 in. (175 mm)
•
Depth: 2 in. (51 mm)
•
Metal-cover model dimensions
For complete dimensional drawing, see Figure 2 on page 3.
Height: 9.0 in (25 mm)
•
•
Width: 10.37in. (263 mm)
•
Depth: 2.25 in. (58 mm)
Clearances
For wiring, ventilation, and maintenance, provide the following minimum
clearances for the controller:
Plastic-cover model
Front: 4.0 in. (102 mm)
•
Each side: 1.0 in. (25 mm)
•
Top and bottom: 4.0 in. (102 mm)
•
Metal-cover model
Front: 24.0 in. (610 mm)
•
•
Each side: 2.0 in. (51 mm)
•
Top and bottom: 1.0 in. (25 mm)
CNT-SVX06B-EN
