CNT-SVX06B-EN
Chapter 1
Overview and specifications
This guide provides installation and configuration information for the
Tracer ZN511 zone controller, as well as a description of its operations.
The overview includes a product description, specifications, and descrip-
tions of ancillary products that may be necessary.
Product description
The Tracer ZN511 is an application-specific controller that provides
direct-digital zone temperature control. The controller can operate as a
stand-alone device or as part of a building automation system (BAS).
Communication between the controller and a BAS occurs via a LonTalk
communication link, which is based on the LonTalk protocol.
The controller is designed to be field-installed and is sent from the factory
unconfigured. You can configure the controller, using the PC-based Rover
service tool, to support either of the following configurations:
Water-source heat pumps, one or two compressors
•
1 heat/1 cool fan coils with two-position valves
•
Note:
For information about using the Rover service tool, see the
Rover Installation/Operation/Programming guide (EMTX-
SVX01A-EN).
Storage environment
If a Tracer ZN511 zone controller is to be stored for a substantial amount
of time, store it in an indoor environment that meets the following
requirements:
•
Temperature: –40° to 185°F (–40° to 85°C)
•
Relative humidity: 5–95%, noncondensing
1
