Item
IPSec Security Method
4 . 1 0 . 8 L A N t o L A
4 . 1 0 . 8 L A N t o L A
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPSec Tunnel, and
L2TP by itself or over IPSec) and corresponding security methods, etc.
The router supports up to 32 VPN tunnels simultaneously. The following figure shows the
summary table.
Each item will be explained as follows:
Description
Pre-Shared Key - Check the box of Pre-Shared Key to invoke
this function and type in the required characters (1-63) as the
pre-shared key.
Digital Signature (X.509) – Check the box of Digital
Signature to invoke this function and Select one predefined
Profiles set in the VPN and Remote Access >>IPSec Peer
Identity.
This group of fields is a must for IPSec Tunnels and L2TP
with IPSec Policy when you specify the remote node. Check
the Medium, DES, 3DES or AES box as the security method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option is
invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
Local ID - Specify a local ID to be used for Dial-in setting in
the LAN-to-LAN Profile setup. This item is optional and can
be used only in IKE aggressive mode.
N
N
203
Vigor2920 Series User's Guide
