Management - Draytek Vigor2920 Series User Manual

Item
Server IP Address
Time Zone
Enable Daylight Saving
Automatically Update
Interval
Click OK to save these settings.
4 . 1 5 . 9 M a n a g e
4 . 1 5 . 9 M a n a g
This page allows you to manage the settings for access control, access list, port setup, and
SMP setup. For example, as to management access control, the port number is used to
send/receive SIP message for building a session.
Available parameters are explained as follows:
Item
Router Name
Allow management from
the Internet
Disable PING from the
Internet
Vigor2920 Series User's Guide
Description
Type the IP address of the time server.
Select the time zone where the router is located.
Check the box to enable the daylight saving. Such feature is
available for certain area.
Select a time interval for updating from the NTP server.
m e n t
e m e n t
Description
Type in the router name provided by ISP.
Enable the checkbox to allow system administrators to login
from the Internet. There are several servers provided by the
system to allow you managing the router from Internet. Check
the box(es) to specify.
Check the checkbox to reject all PING packets from the
Internet. For security issue, this function is enabled by default.
286
