Introduction
The DP CyberSerial PCI high-speed serial card
provides one RS232 9-pin serial port.
Key Features and Benefits
•
Universal PCI card design that works in
32-/64-bit 3.3V/5V PCI and PCI-X slots
•
Installs in standard height or low profile
chassis with included brackets
•
Provides 1 RS-232 serial port
•
The serial port can be independently
configured with 5V or 12V power output
System Requirements
•
Pentium or equivalent computer with an
available PCI slot
•
Windows
bit) / XP (32-/64-bit) / Server 2003 & 2008
(32-/64-bit) / Server 2008 R2 / 2000 / ME
/ 98SE / 98 / 95
04-0706A
DP CyberSerial PCI
Quick Installation Guide
7 (32-/64-bit) / Vista (32-/64-
®
1
Advertisement
Table of Contents
Related Manuals for SIIG DP CyberSerial PCI
Summary of Contents for SIIG DP CyberSerial PCI
-
Page 1: Quick Installation Guide
DP CyberSerial PCI Quick Installation Guide Introduction The DP CyberSerial PCI high-speed serial card provides one RS232 9-pin serial port. Key Features and Benefits • Universal PCI card design that works in 32-/64-bit 3.3V/5V PCI and PCI-X slots • Installs in standard height or low profile chassis with included brackets •... -
Page 2: Package Contents
Package Contents • DP CyberSerial PCI board • 1x Jumper • Spare low profile bracket • Driver CD • Quick installation guide Layout Power connector (optional) Serial port Figure 1: Board Layout Jumper Settings (JP1) Open = 0 volts (default) -
Page 3: Hardware Installation
Power Connector (optional) Connects to the system's power supply. This connection is required when the serial port is configured for 5V or 12V power output. Note: Most serial devices do not require additional power through the serial port. Refer to your serial device's manual for more information. - Page 4 Note: For low profile systems, replace the currently mounted bracket with the spare low profile bracket now. Turn OFF the power to your computer and any other connected peripheral devices. Unplug the power cord from the computer. Remove the computer cover. Remove the slot bracket from an available PCI slot.
-
Page 5: Driver Installation
Driver Installation Please make sure the board is installed before proceeding with driver installation. Windows 7 (32-/64-bit) Install the board and boot up Windows. Right click Computer, click Manage, click Device Manager. Insert the driver CD. Right click PCI Device, click Update Driver Software. - Page 6 Windows Vista (32-/64-bit) Install the board and boot up Windows. At the Found New Hardware window, click Locate and install driver software (recommended), then click Continue. Insert the driver CD. Click Don't search online. (Skip this step if not prompted) Click I don't have the disc.
- Page 7 Windows XP (32-/64-bit) / Server 2003 (32-/64-bit) Install the board and boot up Windows. Insert the driver CD. Select No, not this time, click Next. (Skip this step if not prompted) Select Install the software automatically (Recommended), then click Next. (Skip this step if not prompted) Click Finish.
- Page 8 Click I don't have the disc. Show me other options. (Skip this step if not prompted) Click Browse my computer for driver software (advanced). (Skip this step if not prompted) Type D:, then click Next. (Change D: to match your CD/DVD-ROM drive letter) At The sofware for this device has been successfully installed, click Close.
- Page 9 At Windows has successfully updated your driver software, click Close. Right click PCI Serial Port, click Update Driver Software. Repeat steps 4-6. Right click CyberSerial Communication Port, click Update Driver Software. Repeat steps 4-6 to complete the installation. Windows 2000 At the Found New Hardware Wizard, click Next.
- Page 10 For Server 2008: Right click Computer, click Manage, double click Diagnostics, click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial ... 16Cxxx ... should be displayed. Double click Multifunction adapters, SIIG CyberPro 1S board should be displayed.
- Page 11 Windows ME At the Add New Hardware Wizard, choose Specify the location of the driver (Advanced), click Next. Check Specify a location, uncheck the other box, insert the driver CD, type in D:\9x, then click Next. (Change D: to match your CD-ROM drive letter) Click Next and Finish.
- Page 12 Click Next, then Finish. Repeat steps 1-4. Restart Windows to complete the installation. Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD, and click Other Locations. Type in D:\9x, click OK, then Finish. (Change D: to match your CD-ROM drive letter) From the Insert Disk window, click OK.
-
Page 13: Installation
Device Manager. Double click Ports (COM & LPT), CyberSerial... 16Cxxx... should be displayed. Double click Multi-function adapters, SIIG CyberPro 1S PCI board should be displayed. Changing COM Port Address Some serial devices need a specific COM port in order to work. If your serial device works properly, do not change this setting. - Page 14 Click the down arrow next to the COM Port number box, select a COM port that is not in use. Click OK. Click OK, then close Device Manager to save the changes. Windows ME / 98SE / 98 / 95 From the Device Manager window double click Ports (COM &...
-
Page 15: Technical Support And Warranty
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued. - Page 16 Fremont, CA 94538-3152, USA Phone: 510-657-8688 DP CyberSerial PCI is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
