6.2.2
Antenna
The choice of the antenna sub-system (type, performance, cable length and thermal resistance, etc.) and its
integration in the application is a major issue. These elements could affect the performance of the GSM
features such as sensitivity and transmitted power.
It is recommended to shield the application.
For applications including an antenna, poor shielding could dramatically affect the sensitivity of the terminal.
Therefore, the antenna should be isolated to the maximum extent possible from the digital circuitry
(application digital circuits and Integra Wireless CPU
antenna could affect the application.
Product used within 20 cm from the head or body is required to undergo SAR testing. Because of the
industrial application of the Integra M2106+, the Wireless CPU
should make sure that the antenna placed is having a minimum distance of 20cm from human body.
6.2.3
Minimum Hardware Interface to Get Started
As a minimum, it is necessary to connect the following signals to operate the Integra M2106+ Wireless CPU
correctly within an application:
Minimum signals required to operate the Integra Wireless CPU
See section 3.6 for implementation of the serial link level shifter
©Confidential
This document is the sole and exclusive property of Wavecom. Not to be distributed or divulged without prior written
agreement.
WA_DEV_M2106+_PTS_003-001
Pin #
Signal
1
GND
2
GND
3
+5 V
4
+5 V
6
GND
13
CT106/CTS
15
ON/OFF
21
GND
24
GND
25
CT103/TX
28
CT104/RX
30
CT105/RTS
*
Connected to + 5 V for example
Using the Integra Wireless CPU
®
interface). If not, the power transmitted through the
®
has not been qualified for SAR. Customer
Description
GROUND
GROUND
Power supply
Power supply
GROUND
Clear To Send
Power On/OFF*
GROUND
GROUND
Transmit
Receive
Request To Send
Integra M2106+
®
®
®
:
Page: 59 / 77
April, 2007
