Connections

is designed to be flexible and can support both instrument and line-level inputs and
outputs. Rear panel toggle switches allow you to independently select input and output
levels. Audio Inputs and Outputs accept standard mono (unbalanced) ¼" phone plugs.
can be connected directly to your guitar, behind another pedal, in your Amp's effects
loop or to your mixer's send/return or insert. Given the variety of guitars, effects pedals, amps
and mixers, we can't describe a 'best' setup. The setup should be driven by you and the
sound that you're going for. That writ, here are some suggestions and typical setups.
Note: It's usually best to connect
gates.
Mono/Stereo
detects which input and output jacks have cables plugged in and routes audio I/O
accordingly. With a Mono Input (Input 1) and Stereo Outputs, the dry contribution for both
outputs comes from the Mono Input (Input 1). With Stereo Inputs, the dry contribution at
Output 1 is from Input 1 and the dry contribution at Output 2 is from Input 2, thereby
maintaining the original signal stereo image.
after distortion effects, compressors, EQs, and noise
