Eventide Space User Manual

Eventide Space User Manual

Stompbox
Hide thumbs Also See for Space:

Advertisement

User
Guide

WARNINGS

Use only with supplied power supply.
Avoid spilling liquids onto/into the unit.
Do not expose to excessive heat or moisture.
Do not open – there are no user serviceable parts inside.
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Complete User Guide Part #159029 Rev B
Contents Part #142335 Rev B
Eventide and Harmonizer are registered trademarks of Eventide Inc. ©2011 Eventide Inc.

Advertisement

Table of Contents
loading

Summary of Contents for Eventide Space

  • Page 1: Warnings

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Complete User Guide Part #159029 Rev B Contents Part #142335 Rev B Eventide and Harmonizer are registered trademarks of Eventide Inc. ©2011 Eventide Inc.
  • Page 3: Table Of Contents

    User Guide Table of Contents WARNINGS ......................... 1 Introduction ........................5 A Few Words of Advice...................... 5 Key Features ........................5 The Website ........................5 Overview..........................6 The Basics ........................... 6 Connections........................9 Typical Setups........................10 Bypass..........................14 Selecting Bypass Type ...................... 14 Killdry –...
  • Page 4 User Guide Table of Contents Tempo ..........................33 Tempo ON/OFF........................ 33 Tap Tempo ........................33 Global Tempo........................33 Fine-tuning Tempo and Parameters.................. 33 Tempo..........................33 Parameters ........................33 Dumping (Backing-up) Presets and System Settings............34 Restoring Presets and System Setting ................34 System Mode........................
  • Page 5: Introduction

    Introduction Congratulations on choosing an Eventide stompbox. For years we’ve dreamed of putting our rack mount effects in the hands of performing musicians and, in particular, at the feet of guitar players. is the latest realization of that dream; bringing true studio-quality audio, massive processing power, world-class effects, and unmatched flexibility to your live sound.
  • Page 6: Overview

    User Guide The Basics Overview The Basics There are a few basic concepts that you’ll have to grasp to use successfully. If you read nothing else, please read this section. The Algorithms offers a wide range of reverb-type effects and comes loaded with 100 Preset effects. These effects are based on twelve unique algorithms.
  • Page 7 User Guide The Basics Using the Encoder to Select Presets Presets can be loaded by simply turning the Encoder and stopping at the Preset that you’d like to use. When the Preset loads, the name of the Algorithm on which the Preset is based is displayed momentarily.
  • Page 8 User Guide The Basics The Middle and Right Footswitches are used to scroll through the Presets. The Middle Footswitch decrements and the Right Footswitch increments. Notice that the Preset Number flashes to indicate that the Preset has not yet been loaded. You must press the Left Footswitch to load the cued preset.
  • Page 9: Connections

    User Guide Connections Connections is designed to be flexible and can support both instrument and line-level inputs and outputs. Rear panel toggle switches allow you to independently select input and output levels. Audio Inputs and Outputs accept standard mono (unbalanced) ¼” phone plugs. can be connected directly to your guitar, behind another pedal, in your Amp’s effects loop or to your mixer’s send/return or insert.
  • Page 10: Typical Setups

    User Guide Connections Typical Setups Here are some suggested ways of connecting to your rig and suggested I/O level switch settings: Guitar > > Amp - Mono In/Mono Out This is the simplest way to connect . Connect your guitar cable to Input 1 and a cable from Output 1 to your amp.
  • Page 11 User Guide Connections Guitar > > Amp1/Amp2 – Mono or Stereo In/Stereo Out Connect your guitar cable to Input 1 and a cable from Output 1 to one amp and a second cable from Output 2 to the other amp. Input Level switch (In Lvl) should be set to GUITAR and Output Level switch (Out Lvl) set to AMP.
  • Page 12 User Guide Connections Guitar > Amp Effects Send > > Amp Effects Return If your Amp has an Effects Loop, you can connect ’s Input to the Amp Effect Loop Send ’s Output to the Amp Effect Loop Return. Most guitar amp’s Effects Loops run at Line Level so set ’s Input and Output Level Switches to “Line.”...
  • Page 13 User Guide Connections Mixer Effects Send> > Mixer Effects Return When connecting to a Mixer, set ’s Input and Output Level Switches to “Line.”...
  • Page 14: Bypass

    User Guide Setup Bypass It’s important to select the Bypass function that works best with your setup. gives you the choice of Bypass type – DSP Bypass, Relay Bypass or DSP+FX Bypass. ’s default Bypass setting is DSP Bypass. DSP Bypass When set to DSP Bypass, bypassing sends the audio at the DSP’s inputs directly to the outputs without any effects processing.
  • Page 15: Killdry - Send/Return Loop

    User Guide Setup Note: When connecting to a computer, we suggest that you use a dedicated audio interface and to select the type of Bypass that works best for your application. Note: has been carefully designed to not mess with your tone in any of the Bypass settings.
  • Page 16: Setting Output Levels

    User Guide Setup Setting Output Levels Preset output levels can be adjusted in either Play or Preset Mode. To set output level: Press Left Footswitch to Bypass the Preset. Press and hold the Left Footswitch, the Preset will now be Active. After holding for 1 second the display will show “O/P LVL 0dB”...
  • Page 17: Algorithms & Presets

    User Guide Algorithms Algorithms & Presets ’s Presets are based on a set of reverb-type audio processing algorithms. An algorithm is the underlying structure of the effect that the Preset is built upon. Please refer to the included Preset Reference Sheet and to our on-line documentation for descriptions of ’s Presets.
  • Page 18: The Algorithms

    User Guide Algorithms The Algorithms ’s 12 Algorithms are the basis for all of its Presets. Each Algorithm employs a unique signal processing structure to achieve its effect and each Algorithm has a unique set of control parameters associated with it. Some of ’s Algorithms are designed to simulate the sound of real-world enclosures and devices like halls and rooms and plates and springs.
  • Page 19 The controls allow for precision tweaking of early reflections, late reverb, and EQ. Room is the workhorse Algorithm for placing a sound in a realistic space or adding that subtle fattening that isn’t immediately noticed but is always immediately missed.
  • Page 20 User Guide Algorithms Mix – [VERBMIX]: wet/dry between reverb and tremolo dry signal Decay – [DECAY]: decay in seconds or note-based in Tempo Mode Size – [TENSION]: goes from more tension (all the way left) to less tension (all the way right) Delay –...
  • Page 21 ModEchoVerb is based on a popular reverb structure from the Eventide H8000 that brought about such presets as "Echo Space of God" and "Glorious Flange Canyon." It feeds the output of an infinite reverb into an infinite feedback delay and slathers on an extra helping of modulation.
  • Page 22 [SMP/HLD] (sample/hold), [ENVELOP], [ADSR], or [EXP PDL] (Expression Pedal) DynaVerb DynaVerb couples an Eventide Eclipse reverb with a model of the Eventide Omnipressor® to create an adaptable dynamics reverb. The Omnipressor is capable of all types of dynamics processing from gating, expansion, compression, limiting, and even its signature "dynamic reversal,"...
  • Page 23 User Guide Algorithms Contour – [SC IN 10 + RV 10]: the mixer to sidechain input (gain control signal). At all the way left, the gain curve is derived from the input only. At all the way right, it is a feedback dynamics unit with gain derived from the reverb output.
  • Page 24: Catchup

    User Guide Catchup Catchup You would expect that when you turn a Parameter Control Knob, the parameter’s value would change instantly and, unless Catchup is enabled, it does. Instant changes, however, may not be desirable for all situations and users. Consider the following example: You have just loaded a preset based on Room and the preset’s value for the Decay is set to 1 second.
  • Page 25: Expression Pedal

    Expression Pedal can be set up to control any combination of the ten parameters. For proper operation the Expression Pedal should be a simple linear resistive potentiometer (“pot”) with a maximum value of between 5k Ohms and 25k Ohms. Refer to www.eventide.com for information on recommended expression pedals.
  • Page 26 User Guide Expression Pedal to un-assign Delay and have it fixed at 20 milliseconds rather than have it change when the Pedal moves. Here’s what you do: Press the Pedal to full heel and turn the Delay knob to 20 milliseconds. Press the Pedal to full toe.
  • Page 27: The Footswitches - Play And Preset Mode

    User Guide The Footswitches The Footswitches – Play and Preset Mode ’s footswitches are multi-purpose and operate in one of three modes, Play Mode, Preset Mode, and System Mode. In normal use, is in either Play Mode or Preset Mode. System Mode is used to set up MIDI, external controls and various system parameters.
  • Page 28: Tap Footswitch

    User Guide The Footswitches HotSwitch Programming In Play Mode, the HotSwitch is always active and programmable, i.e., HOT. To program, press and hold the Middle Footswitch (HotSwitch) and turn any combination of the parameter Control Knobs to achieve the sound that you desire for the HotSwitch. This will be the sound you’ll hear when the HotSwitch RED LED is lit.
  • Page 29: Preset Mode

    User Guide The Footswitches Preset Mode In Preset Mode, the Billboard displays the Preset Number followed by the first 10 characters of the Preset Name of the currently loaded Preset. The Left Footswitch is used for loading and Bypassing Presets. Note: Each of the 100 Presets can be based on any of the Algorithms.
  • Page 30 User Guide The Footswitches The factory default sets the number of active Presets to 100 (Preset#1 to Preset#100). To limit the number of active Presets: Press and hold the Encoder and Right Footswitch simultaneously for a few seconds to enter System Mode. Release the Encoder. Turn the Encoder until [UTILITY] is displayed.
  • Page 31: Saving Presets

    Preset Number field. Pressing the Left Footswitch again will jump to the last character. Note: A phantom space is always present at the end of the name to allow characters to be added past the end. This cannot be deleted but will be removed on exit.
  • Page 32: Auxiliary Switches

    3) Simultaneously pressing the switch assigned to the Tip and the switch assigned to the Ring will trigger the function assigned to the Tip+Ring. Refer to www.eventide.com for information on recommended Aux Switches. MIDI MIDI In, Out, Thru are supported.
  • Page 33: Tempo

    Space User Guide Tempo Tempo Tempo ON/OFF Tempo is turned ON or OFF by momentarily pressing the Tempo Button. When Tempo is ON, the Tempo LED flashes at the Tempo rate. With Tempo OFF, the Tempo LED is OFF. Tap Tempo In Play Mode, the Tap Footswitch can be tapped to set the tempo.
  • Page 34: Dumping (Backing-Up) Presets And System Settings

    Turn the Encoder to choose SysEx ID from [1] to [16]. Press and hold the Encoder and Right Footswitch simultaneously for a few seconds to exit System Mode. Note: The Eventide Update Utility (EUU) will only work if SysEx ID is set to 1.
  • Page 35: System Mode

    User Guide System Mode System Mode System Mode is used for settings that apply to the overall system such as the Bypass, Aux Switch, MIDI, etc. To Enter/Exit System Mode Press and hold the Encoder and Right Footswitch simultaneously for a few seconds to enter and exit the System Mode.
  • Page 36: System Menu Tree

    User Guide System Mode System Menu Tree The system mode is divided into five categories [BYPASS], [AUX SWITCH], [MIDI], [GLOBAL], and [UTILITY] which are the top-level menu items that appear when entering system mode. In the following, factory default settings are indicated in (bold) [BYPASS] –...
  • Page 37 User Guide System Mode To assign the switches, first select the parameter or function (the destination) that you want to externally control (Intensity for example) and then select the Aux Switch that you want to control it with (the source). The default settings for the Aux Switches are: TIP - BYPASS RING - HOTSW...
  • Page 38 User Guide System Mode When a Parameter Control Knob designator is displayed (KNOB0… KNOB9), pressing the Left Footswitch will display [MIN VAL]. Turn the associated Parameter Control Knob to set the minimum value. For example, if KNOB0 was selected, turn the Mix Control Knob to set the minimum value.
  • Page 39: [Midi] - Midi Functions

    User Guide System Mode [MIDI] - MIDI Functions After entering System mode, turn the Encoder to select [MIDI], and then press the Encoder to enter the MIDI functions settings mode. Turn the Encoder to scroll through the MIDI functions including MIDI Program maps, MIDI channel, MIDI Data Dumps, etc.
  • Page 40 User Guide System Mode After you’ve selected a Parameter Control Knob, you can set the parameter range that the MIDI CC will control by setting minimum and maximum parameter values. When a Parameter Control Knob designator is displayed (KNOB0… KNOB9), pressing the Left Footswitch will display [MIN VAL].
  • Page 41 User Guide System Mode PEDAL>C15,KNOB0>C22,KNOB1>C23,KNOB2>C24,…,KNOB9>C31 XMT CC makes it possible to use ’s Expression Pedal, Control Knobs and Aux Switches as MIDI controllers. Here’s how it works: Press the Encoder to select XMT CC. You will see two fields (split display) of the Billboard display showing Control Source and Destination assignments.
  • Page 42 MIDI Out jack or USB to control an external device - e.g., another Eventide Stompbox, an Eventide Eclipse, an Eventide H8000FW, etc. To Create a MIDI Program Change transmit map, Press the Encoder to access the MIDI transmit map for editing.
  • Page 43 User Guide System Mode [PGM XMT] – MIDI Program Change Transmit Enable (ON, OFF) Press the Encoder to select. Turn Encoder to set MIDI Program Change transmit ON or OFF. If ON, a MIDI Program change message is transmitted whenever a Footswitch is pressed for Preset load.
  • Page 44 User Guide System Mode Press the Middle Footswitch twice to go to the top level System menu. [CLK FILTER] – MIDI Clock Filter Enable (ON, OFF) Press the Encoder to select. Turn Encoder to set MIDI Clock Filtering ON or OFF. If ON, can be used with an unstable MIDI Clock source, but will be slower and less precise at tracking clock speed changes.
  • Page 45: [Global] - Global Settings

    User Guide System Mode [GLOBAL] – Global Settings [MIX] – Enable Global MIX (ON, OFF) Press the Encoder to select. Turn Encoder to set Global MIX. Mix is always stored with Presets, but the stored value is not used if Global Mix is ON. With Global ON, the current Global Mix is used for all Presets.
  • Page 46 User Guide System Mode [PRESET RANGE] – Select the range of Active Preset (1 - 100) Press the Encoder to select. Press the Left Footswitch to select the lower limit and the Right Footswitch to select the higher limit. Turn Encoder to set the lowest and the highest active Preset.
  • Page 47: Restoring Factory Settings/Software Updates

    Middle Footswitch and the Encoder until [INITIALIZING] is displayed. Software Updates ’s software can be upgraded over USB. To enable the software update, power up while pressing the Middle Footswitch until [UPDATE] is displayed. Information on software updating can be found at www.eventide.com.
  • Page 48: Midi Implementation Chart

    User Guide MIDI Implementation Chart MIDI Implementation Chart Mode 1: Omni On, Poly Mode 2: Omni On, Mono O=Yes Mode 3: Omni Off, Poly Mode 4: Omni Off, Mono X=No Function Transmitted Recognized Remarks Default 1-16 1-16 Basic Channel Changed 1-16 1-16 Default...
  • Page 49: Specifications

    User Guide Specifications Specifications Analog I/O Input Impedance 500k ohms (mono) 1 Meg (stereo) Output Impedance 470 ohms Recommended Load Impedance 10k ohms or greater Connectors Input 1 (mono) - ¼ inch mono phone jack Input 2 - ¼ inch mono phone jack Output 1 (mono) –...
  • Page 50: Limited Warranty

    When the warranty becomes effective The one-year warranty period begins on the day the unit is purchased from an Authorized Eventide Dealer or, if the unit is drop-shipped from Eventide, on the day shipped, plus a reasonable allowance for shipping delays. This applies whether or not you return your warranty registration form.
