TriceraChorus Quick Reference Guide
Mix
Left: 0-99 Mix of Chorus voices
Center: 100 Vibrato mode (no dry)
Right: 99-0 Mix of Chorale voices
Left
Modulation Depth of
the Left channel voice
Preset LED Ladder
ACTIVE Button/LED
LED lit when ACTIVE
Press to toggle action of
ACTIVE Footswitch
LATCHING< >MOMENTARY
ACTIVE/BYPASS
Preset Mode: Load Preset
Rate
Chorus modulation rate 0.1-20 Hz
controlled by external Tap switch or
sync'd to MIDI Clock when enabled
SWIRL/Preset
Press & Hold to toggle between
Preset Select and SWIRL Modes
Detune
Mix for the stereo Detune
section, independent of
the Chorus/Chorale Mix
Button/LED
Toggles Primary/Secondary
Parameter Control
LED ON = Secondary
LED OFF = Primary
Right
Modulation Depth of the
Right channel voice
Center
Modulation Depth of the
Center channel voice
SWIRL Button/LED
LED OFF = Preset Select Mode
LED RED = SWIRL Mode
LED GREEN = SWIRL is ON
Press & Hold to Save Preset

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TriceraChorus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eventide TriceraChorus

Summary of Contents for Eventide TriceraChorus

  • Page 1 TriceraChorus Quick Reference Guide Rate Detune Chorus modulation rate 0.1-20 Hz Mix for the stereo Detune controlled by external Tap switch or section, independent of Left: 0-99 Mix of Chorus voices sync'd to MIDI Clock when enabled the Chorus/Chorale Mix...
  • Page 2 Knob Functions – Secondary Parameters Pitch Press button to toggle Rate Env Secondary/Primary parameters Stereo detune (in cents) Controls amplitude enve- Fully CCW: -40L/+40R lope amount sent to the Center: 0L/0R rate of the LFOs Fully CW: +40L/-40R Mix Env Filter Controls amplitude CCW: Low Cut...

  • Page 3: Expression Pedal

    Expression Pedal MIDI Messages Morphing from Heel to Toe Save Preset Enter Save Mode by pressing and holding the SWIRL An Expression Pedal can be used to change any Button, then a MIDI program change message will save grouping of knob Parameters in one smooth a Preset to the Preset Slot of the given value 1-127.

  • Page 4: Enter System Setup

    System Setup Enter System Setup To access these Global Settings, apply power while holding ACTIVE Footswitch and button. Top two LEDs light when in System Setup. Changes are stored as they are made. Cycle power to exit System Setup. Set MIDI Channel Set Bypass Mode Set Exp Pdl Jack BUFFER...

  • Page 5: Load Presets

    Presets - 5 On Board, 127 Via MIDI The currently loaded Preset is indicated on the Preset LED Ladder. When a Preset is modified the Preset LED blinks once. Load Presets Save Presets To select and load a Preset using Footswitches: To save one of the 5 Presets using the Buttons: 1.
  • Page 6 Preset Mode Press SWIRL Footswitch to activate SWIRL LED RED SWIRL OFF Swirl adds another dimension to TriceraChorus’ sound via stereo phase shifters after the Detune section to create throbbing and swooshing effects. LED GREEN SWIRL ON The amount of Swirl depends on the greater level of either Chorus Mix or Detune Mix and follows the Env Mix control.
