Rose
Preset
Ladder
Preset
Press – Select Preset
Hold – Save Preset
Lit – Preset Loaded
Delay
Turn – Fine Delay
Push and Turn – Coarse Delay
Comb Delay – Flip Phase
Long Delays – Reverse Delay
Filter
Analog Low Pass Filter
Active LED
Red – Preset Active
Green – Preset Modified
Quick Reference Guide
®
Mix
Analog Dry/Wet Mix
multi-dimensional controls, feedback can go crazy
Enter Preset Mode
Active/Bypass
Preset Load
Feedback
Analog Feedback to the Delay Line
Warning: Due to Rose's analog signal path and
Depth
Modulation Intensity
Shape/Bank
Ladder
Shape
Modulation Source
Rate
Modulation Speed
Delay Multiplier On/Off
Hotswitch LED
Hotswitch
Preset Select

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rose and is the answer not in the manual?

Questions and answers

Summary of Contents for Eventide Rose

  • Page 1 ® Feedback Preset Analog Feedback to the Delay Line Ladder Analog Dry/Wet Mix Depth Warning: Due to Rose’s analog signal path and multi-dimensional controls, feedback can go crazy Modulation Intensity Shape/Bank Ladder Preset Press – Select Preset Hold – Save Preset Lit –...
  • Page 2: Adjusting Delay

    Delay Multiplier HOLD Rose is capable of very short delays for COMB and flanging effects and for extreme delays, up to 50 seconds, for looping and reverse effects. Delay is divided into ten ranges. Press the Delay Knob to display the current Delay...
  • Page 3 Using Alternate Settings: ALT A/B Use the Hotswitch or Aux Switch (or MIDI CC#27) to toggle between A&B OR morph using an Expression Pedal. Tip: When creating a new preset, you can copy all A settings to B by pressing and holding      and   . Tip: Hold down     ...
  • Page 4 Set HOTSWITCH Function Set MIDI Channel/CC HOLD HOLD HOLD TO TOGGLE TAP TEMPO Delay Delay INFINITE REPEAT HOLD MOD CLICK CLICK CLICK RESET MOD 4 5... ALT A/B Pause Modulation EXIT EXIT Set MIDI Channel (default=1): Click Shape Set MIDI Expression CC (default=7):Click Restart Modulation/LFO Set Auxiliary Switch Function MIDI Clock On/Off...
  • Page 5: Save Preset

    - The ACTIVE LED turns green when a preset is modified - Press Preset Button to select Preset indicated by Preset Ladder LED - Use Eventide Device Manager to manage your presets - Press and Hold the Preset Button until LEDs flash rapidly to save Preset...
  • Page 6 Boot pressing HOTSWITCH & Button. Device Manager Software eventideaudio.com/devicemanager Instructional Videos eventideaudio.com/rose Technical Support eventideaudio.com/support Follow us on social Rose Quick Reference Guide for Firmware v3.0+ | Eventide Part#141303 Rose and Eventide are registered trademarks of Eventide Inc. © 2020 Eventide Inc.
