User Guide
PEDAL>C15,KNOB0>C22,KNOB1>C23,KNOB2>C24,...,KNOB9>C31
XMT CC makes it possible to use
as MIDI controllers.
Here's how it works:
Press the Encoder to select XMT CC. You will see two fields (split display) of the Billboard
display showing Control Source and Destination assignments. The Left Footswitch LED is
flashing (if its not, press the Left Footswitch to select this field) showing this to be the
selected field for editing.
To Select the Control Source
Turn the Encoder knob to select the Control Source. The choices are:
PEDAL
KNOB0...9
TIP
RING
T+R
To Assign the Control Source to a Destination
Press the Right Footswitch to select the MIDI Continuous Control that will be assigned to the
Control Source. The choices are:
OFF – Control Source unassigned.
C0 - C99 - MIDI Continuous Controller from 0 to 99.
Press the Left and Right Footswitches to toggle between Source and Destination to make as
many assignments as you wish.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to the top level System menu.
[RCV MAP] – Create a MIDI Program Change Receive Map
MIDI maps are an efficient way to instantly recall any of
MIDI controller (pedal board, sequencer, etc.).
Press the Encoder to select and create a MIDI Program Change Receive Map. This function
sets the corresponding Preset that is recalled when a MIDI Program Change message is
received. (Referred to as Prg No. from here on.)
Note that if a Preset is saved "Bypassed," when it is loaded by using a MIDI Program Change
command the Preset will load but the pedal will be Bypassed.
The left field displays the Prg No. (0-127) and Right Field displays either the Preset Number (1-
100) or one of various Bypass options described below, or OFF.
There are two ways to select the MIDI Prg No: manually or using Learn Mode. To select
manually, with the Left Footswitch LED flashing, turn the Encoder to select the desired Prg
No. from 0 to 127.
To use Learn Mode, press the Left Footswitch again. In LEARN mode, the Prg. No. will be
automatically set when a MIDI Program Change message is received. Pressing the Left
Footswitch exits LEARN mode.
's Expression Pedal, Control Knobs and Aux Switches
Expression Pedal
Parameter Control Knobs
Aux Switch Tip
Aux Switch Ring
Aux Switch Tip+Ring
41
System Mode
's Presets using your favorite
