UltraTap Quick Reference Guide
Taps
Number of Delay Taps
Mix
Dry/Wet Mix
Feedback
Repeats of a Length-valued
delay that is fed back around
the entire multi-tap machine
Preset LED Ladder
ACTIVE Button/LED
LED lit when ACTIVE
Press to toggle action of
ACTIVE Footswitch
LATCHING< >MOMENTARY
ACTIVE/BYPASS
Preset Mode: Load Preset
Length
Total time over which Taps
are spaced. 4 sec max
TAP/Preset
Press & Hold to toggle between
Preset Select and Tap Modes
Button/LED
Toggles Primary/Secondary
Parameter Control
LED ON = Secondary
LED OFF = Primary
Taper
Left to fade up
Right to fade down
Center for equal level of all taps
Spread
Spacing of Taps
Turn left for "slow-down"
Turn right for "speed-up"
Center for constant spacing
TAP Button/LED
LED OFF = Preset Select Mode
LED ON = Tap Time in Seconds
LED Blinks = Tap Tempo in BPM
Press to toggle Tap Time/Tempo
Press & Hold to Save Preset

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraTap and is the answer not in the manual?

Questions and answers

Related Manuals for Eventide UltraTap

Summary of Contents for Eventide UltraTap

  • Page 1 UltraTap Quick Reference Guide Button/LED Taps Length Toggles Primary/Secondary Number of Delay Taps Total time over which Taps Parameter Control are spaced. 4 sec max LED ON = Secondary LED OFF = Primary Dry/Wet Mix Taper Feedback Left to fade up...

  • Page 2: Rear Panel

    Knob Functions – Secondary Parameters Slurm Predelay Press button to toggle Tap slurring/smearing/ Secondary/Primary parameters Time before 1 Tone modulation 1 sec max Turn left for dark, right for bright taps Spd/Rise/Rel Chop parameter control Chop LFO, SPD controls LFO Rate “Chopping”...

  • Page 3: Expression Pedal

    Expression Pedal MIDI Messages Morphing from Heel to Toe Save Preset An Expression Pedal can be used to change any Enter Save Mode by pressing and holding the TAP grouping of knob Parameters in one smooth Button, then a MIDI program change message will save gesture.

  • Page 4: Enter System Setup

    System Setup Enter System Setup To access these Global Settings, apply power while holding ACTIVE Footswitch and button. Top two LEDs light when in System Setup. Changes are stored as they are made. Cycle power to exit System Setup. Set MIDI Channel Set Bypass Mode Set Exp Pdl Jack BUFFER...

  • Page 5: Load Presets

    Presets - 5 On Board, 127 Via MIDI The currently loaded Preset is indicated on the Preset LED Ladder. When a Preset is modified the Preset LED blinks once. Load Presets Save Presets To select and load a Preset using Footswitches: To save one of the 5 Presets using the Buttons: 1.
  • Page 6 Restore Factory Settings: Boot pressing ACTIVE Footswitch & ACTIVE Button Software Update: Boot pressing TAP Button & TAP Footswitch UltraTap QRG for Firmware v1.0+| Eventide Part #141346 Rev A. Eventide is a registered trademark of Eventide Inc. © 2021 Eventide Inc.
