MicroPitch Delay Quick Reference Guide
Pitch B
Pitch A
Button/LED
Pitch of B Channel (right)
Pitch of A Channel (left)
from 0 to -50 cents
Toggles Primary/Secondary
from 0 to 50 cents
Parameter Control
LED ON = Secondary
Mix
LED OFF = Primary
Dry/Wet Mix
Depth
Pitch Mix
Amount/Intensity of
Mix of Pitches A&B
Pitch modulation
Mono Out: Center 50/50
from the LFO or ENV
Stereo Out: Center A left, B right
Preset LED Ladder
Rate/Sens
LFO Mod Rate: 0.1-10Hz
ACTIVE Button/LED
Env Follower Sens: 0-100
LED lit when ACTIVE
Press to toggle action of
ACTIVE Footswitch
TAP Button/LED
LATCHING< >MOMENTARY
LED OFF = Preset Select Mode
LED ON = Tap Time in Seconds
LED Blinks = Tap Tempo in BPM
TAP/Preset
ACTIVE/BYPASS
Press to toggle Tap Time/Tempo
Press & Hold to toggle between
Preset Mode: Load Preset
Press & Hold to Save Preset
Preset Select and Tap Modes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroPitch Delay and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eventide MicroPitch Delay

Summary of Contents for Eventide MicroPitch Delay

  • Page 1 MicroPitch Delay Quick Reference Guide Pitch B Pitch A Button/LED Pitch of B Channel (right) Pitch of A Channel (left) from 0 to -50 cents Toggles Primary/Secondary from 0 to 50 cents Parameter Control LED ON = Secondary LED OFF = Primary...

  • Page 2: Rear Panel

    Knob Functions – Secondary Parameters Delay A Press button to toggle Delay B Secondary/Primary parameters Pitch A Delay Pitch B Delay Time Mode 0-3 secs Time Mode 0-3 secs Tempo Mode 0-6 secs Tempo Mode 0-6 secs Tone Center Flat Feedback CW High Boost Feedback 0-100%...

  • Page 3: Expression Pedal

    Expression Pedal MIDI Messages Morphing from Heel to Toe Save Preset An Expression Pedal can be used to change any Enter Save Mode by pressing and holding the TAP grouping of knob Parameters in one smooth Button, then a MIDI program change message will save gesture.

  • Page 4: Enter System Setup

    System Setup Enter System Setup To access these Global Settings, apply power while holding ACTIVE Footswitch and button. Top two LEDs light when in System Setup. Changes are stored as they are made. Cycle power to exit System Setup. Set MIDI Channel Set Bypass Mode Set Exp Pdl Jack EXP (Default)

  • Page 5: Load Presets

    Presets - 5 On Board, 127 Via MIDI The currently loaded Preset is indicated on the Preset LED Ladder. When a Preset is modified the Preset LED blinks once. Load Presets Save Presets To select and load a Preset using Footswitches: To save one of the 5 Presets using the Buttons: 1.
  • Page 6 Boot pressing ACTIVE Footswitch & ACTIVE Button Software Update: Boot pressing TAP Button & TAP Footswitch MicroPitch Delay Quick Reference Guide for Firmware v1.0+| Eventide Part# 141347 Rev A Eventide is a registered trademark of Eventide Inc. © 2021 Eventide Inc.
