Eventide MODFACTOR Quick Reference Manual

© 2008 EVENTIDE INC., ONE ALSAN WAY, LITTLE FERRY, NJ 07643 USA
THE EFFECTS
Mix
Feedback
Wah Depth
Q
(Vowel sound in Voc Wah)
Feedback
Q/Range
WWW.EVENTIDE.COM
Feedback
Not Used
(Time offset for type 2)
Number of
Drive / Tone
Stages
(Wave Slew on Opto)
Base
Mix
Frequency
Manual
Mix
Offset
Stereo Width
Mix
for Pan Effect
MODFACTOR
Rotor/Horn
Rotor Speed Horn Speed Tone
Balance
Width
(In Stereo Only)
Stereo Width
(# of Stages on Vintage)
Pitch Spread
Not Used RingMod Hz LowPass Filter
QUICK REFERENCE GUIDE
SHAPE KNOB
The Shape knob allows you to choose the source of
modulation on all effect types. The choices are Sine,
Triangle, Peak, Random, Ramp, Square, SMP/HLD, Envelope,
ADSR, and Expression Pedal (EXP PDL.)
"ENVELOPE" OR "ADSR"
as Modulation Choices
Sensitivity
Sensitivity
Selecting ENVELOP or ADSR with the Shape knob will cause
the modulation to follow the attack of your playing, much
like on an Auto Wah. To adjust for various input levels, the
Speed knob becomes a Sensitivity control. Note that
selecting ENVELOP or ADSR with the Shape knob will cause
Tap Tempo, Slow/Fast/Brake, and S-Mod to have no effect.
You can also select ENVELOP or ADSR with the Mod Source
knob. In this case, the Mod Rate knob becomes a Sensitivity
control.
BOTTOM ROW OF KNOBS (SECONDARY LFO)
D-Mod: [Depth-Mod] Amount of Amplitude Modulation
(AM). This knob "wiggles" the Depth Knob's parameter by a
little to a lot. (Fully counter-clockwise is OFF.)
S-Mod: [Speed-Mod] Amount of Frequency Modulation
(FM). This knob "wiggles" the Speed Knob's parameter by a
little to a lot. (Fully counter-clockwise is OFF.)
Mod Rate: Sets the secondary LFO rate. This knob controls
how fast both D-Mod and S-Mod "wiggle" their targets.
Range is 1/8th of Speed Knob to 8 times Speed Knob (with
Tempo OFF,) or Sync to 1/8th Note Divisions (with Tempo
ON.)
Mod Source: Sets the secondary LFO modulation source.
Choices are Sine, Triangle, Peak, Random, Ramp, Square,
SMP/HLD, Envelope, ADSR, and Pedal.
