Related Manuals for Allied Telesis 48Ts/X
Summary of Contents for Allied Telesis 48Ts/X
-
Page 1: Gigabit Ethernet Switches
Series Layer 3 Stackable Gigabit Ethernet Switches x610-24Ts x610-24Ts/X x610-48Ts x610-48Ts/X x610-24Ts-POE+ x610-24Ts/X-POE+ x610-48Ts-POE+ x610-48Ts/X-POE+ Installation Guide 613-001492 Rev. A... - Page 2 Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has been...
-
Page 3: Electrical Safety And Emissions Standards
Electrical Safety and Emissions Standards This product meets the following standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. -
Page 4: Translated Safety Statements
Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document “Translated Safety Statements” posted on the Allied Telesis website at www.alliedtelesis.com. -
Page 5: Table Of Contents
Product Documentation ............................ 14 Starting a Management Session ........................15 Safety Symbols Used in this Document ......................16 Where to Find Web-based Guides ........................17 Contacting Allied Telesis ..........................18 Online Support ............................18 Email and Telephone Support........................18 Warranty..............................18 Returning Products ............................ - Page 6 Contents AC Power Connector ............................53 Power Over Ethernet Plus (PoE+) ........................54 Power Classes............................54 Power Capacity ............................55 Chapter 2: Virtual Chassis Stacking ......................57 VCStack Introduction ............................58 Features of VCStacking..........................58 The Physical Stack .............................59 Resiliency Link............................60 Resiliency Link Configurations via Switch Ports..................61 Stack Formation ..............................
- Page 7 x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide RJ-45 Twisted Pair Port Pinouts........................116 RJ-45 Style Serial Terminal Port Pinouts ....................... 118 AT-RPS3000 21-pin Connector Pinouts......................118...
- Page 8 Contents...
-
Page 9: List Of Figures
Figure 15. SFP and SFP+ LEDs on x610-24Ts/X and x610-24Ts/X-POE+ Switches............38 Figure 16. SFP LEDs on x610-48Ts and x610-48Ts-POE+ Switches ................39 Figure 17. SFP and SFP+ LEDs on x610-48Ts/X and x610-48Ts/X-POE+ Switches............39 Figure 18. System STATUS LEDs on the Front Panel ......................41 Figure 19. - Page 10 Figures Figure 50. Removing the Dust Plug from an SFP+ Transceiver..................86 Figure 51. Connecting a Fiber Optic Cable to the SFP+ Transceiver..................87 Figure 52. Removing a Dust Plug from a SFP Slot......................92 Figure 53. Installing a Transceiver............................93 Figure 54. DC Terminal Block on the DC AT-PWR250 Power Supply Module ..............96 Figure 55.
- Page 11 Table 3. 10/100/1000Base-T Ports Matched with SFP Slots on 24 Port Switches .............33 Table 4. 10/100/1000Base-T Ports Matched with SFP Slots on x610-48Ts and x610-48Ts-POE+ Switches ....33 Table 5. 10/100/1000Base-T Ports Matched with SFP Slots on x610-48Ts/X and x610-48Ts/X-POE+ Switches ....33 Table 6. Switch Base-T LED Descriptions ..........................37 Table 7.
- Page 12 Tables...
-
Page 13: Preface
Gigabit Ethernet Switches. This preface contains the following sections: “Product Documentation” on page 14 “Starting a Management Session” on page 15 “Safety Symbols Used in this Document” on page 16 “Where to Find Web-based Guides” on page 17 “Contacting Allied Telesis” on page 18... -
Page 14: Product Documentation
Preface Product Documentation For overview information about the software features of the AlliedWare Plus Operating System Software which runs on the x610 Series Switches, refer to: AlliedWare Plus Operating System Software Reference Guide Virtual Chassis Stacking (VCS) How To Note AT-StackXG Stacking Module Installation Guide... -
Page 15: Starting A Management Session
x610 Layer 3 Series Gigabit Ethernet Switches Installation Guide Starting a Management Session For instructions that describe how to start a local management session on a x610 switch, refer to the “Powering on a Switch with a DC AT-PWR250 Power Supply Module” on page 95. For information that describes how to log onto the AlliedWare Plus Operating System Software, see the AlliedWare Plus Operating System Software Reference Guide. -
Page 16: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Table 1. Safety Symbols Symbol Meaning Description Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 17: Where To Find Web-Based Guides
Layer 3 Series Gigabit Ethernet Switches Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 18: Contacting Allied Telesis
Contacting Allied Telesis This section provides Allied Telesis contact information for technical support as well as sales and corporate information. You can request technical support online by accessing the Allied Telesis Online Support Knowledge Base at www.alliedtelesis.com/support and selecting the “Read More”... -
Page 19: Chapter 1: Overview
Chapter 1 Overview This chapter contains the following sections: “Introduction” on page 20 “Switch Descriptions” on page 21 “10/100/1000Base-T Ports” on page 29 “SFP and SFP+ Transceiver Slots” on page 31 “Combo Ports” on page 33 “SD Card Slot” on page 35 “Port LEDs”... -
Page 20: Introduction
There are eight Layer 3 switches in the series: x610-24Ts Switch x610-24Ts/X Switch x610-48Ts Switch x610-48Ts/X Switch x610-24Ts-POE+ Switch x610-24Ts/X-POE+ Switch x610-48Ts-POE+ Switch x610-48Ts/X-POE+ Switch The AlliedWare Plus Operating System Software runs on all of the x610 switches. -
Page 21: Switch Descriptions
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Switch Descriptions The following sections describe the x610 Series Layer 3 Gigabit Ethernet Switches. The x610-24Ts switch has the following hardware features: x610-24Ts Switch 24 10/100/1000Base-T ports Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards... -
Page 22: X610-24Ts/X Switch
Chapter 1: Overview The x610-24Ts/X switch has the following hardware features: x610-24Ts/X Switch 24 10/100/1000Base-T ports Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots Two 10 Gigabit Ethernet small form-factor pluggable plus (SFP+) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards Status LEDs for the ports, transceiver slots, and system Redundant power supply connector... -
Page 23: X610-48Ts Switch
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide The x610-48Ts switch has the following hardware features: x610-48Ts Switch 48 10/100/1000Base-T ports Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards Status LEDs for the ports, transceiver slots, and system Redundant power supply connector... -
Page 24: X610-48Ts/X Switch
Status LEDs for the ports, transceiver slots, and system Redundant power supply connector Fixed 250 watts power supply AT-LBM (Loop Back) module installed in the rear of the switch Figure 4 shows the x610-48Ts/X switch front and rear panel. System and Stack LEDs SD Slot SFP+... -
Page 25: X610-24Ts-Poe+ Switch
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide The x610-24Ts-POE+ switch has the following hardware features: x610-24Ts-POE+ Switch 24 10/100/1000Base-T ports with Power over Ethernet (PoE+) capability. Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards Status LEDs for the ports, transceiver slots, and system Redundant power supply connector... -
Page 26: X610-24Ts/X-Poe+ Switch
Chapter 1: Overview The x610-24Ts/X-POE+ switch has the following hardware features: x610-24Ts/X- POE+ Switch 24 10/100/1000Base-T ports with Power over Ethernet Plus (PoE+) capability. Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots Two 10 Gigabit Ethernet small form-factor pluggable plus (SFP+) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards... -
Page 27: X610-48Ts-Poe+ Switch
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide The x610-48Ts-POE+ switch has the following hardware features: x610-48Ts-POE+ Switch 48 10/100/1000Base-T ports with Power over Ethernet (PoE+) capability. Four Gigabit Ethernet small form-factor pluggable (SFP) transceiver slots An RJ-45 style serial terminal port for local (out-of-band) management One SD slot supporting SD and SDHC cards Status LEDs for the ports, transceiver slots, and system Redundant power supply connector... -
Page 28: X610-48Ts/X-Poe+ Switch
Status LEDs for the ports, transceiver slots, and system Redundant power supply connector AT-LBM (Loop Back) module installed in the rear of the switch Figure 8 shows the x610-48Ts/X-POE+ switch front and rear panel. System and Stack LEDs SD Slot... -
Page 29: 10/100/1000Base-T Ports
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide 10/100/1000Base-T Ports This section describes the 10/100/1000Base-T ports on the switches. The ports are 8-pin RJ-45 connectors that use four pins at 10 or 100 Mbps Connector Type and all eight pins at 1000 Mbps. For the pin assignments, refer to “RJ-45 Twisted Pair Port Pinouts”... -
Page 30: Cable Type
Chapter 1: Overview The cabling requirements for a 10/100/1000Base-T port are: Cable Type For 10 Mbps operation: Standard TIA/EIA 568-B-compliant Category 3 or better shielded or unshielded cabling with 100 ohm impedance and a frequency range that extends to 16 MHz. For 100 Mbps operation: Standard TIA/EIA 568-A-compliant Category 5 or TIA/EIA 568-B-compliant Enhanced Category 5 (Cat 5e) shielded or unshielded cabling with 100 ohm impedance and a frequency range... -
Page 31: Sfp And Sfp+ Transceiver Slots
Copper transceivers allow you to add more twisted pair ports to your x610 Series switch. The x610-24Ts/X, x610-24Ts/X-POE+, x610-48Ts/X, and x610-48Ts/X-POE+ switches feature additional slots for optional Gigabit Ethernet SFP+ transceivers, as listed in Table 2. The SFP+ slots support both fiber optic and copper 10 Gbps transceivers. - Page 32 Chapter 1: Overview Note For a list of supported SFP and SFP+ transceivers, contact your Allied Telesis sales representative.
-
Page 33: Combo Ports
Port 47R with SFP slot 47 Port 48R with SFP slot 48 On the x610-48Ts/X and x610-48Ts/X-POE+ switches, the 10/100/1000Base-T ports 47R and 48R are paired with the two SFP slots to form two combo ports, as listed in Table 5. - Page 34 Chapter 1: Overview Follow these guidelines when using these ports and slots: Only one port in a pair, either a 10/100/1000Base-T port or a corresponding SFP module can be active at a time. A 10/100/1000Base-T port is the active port when its SFP slot is empty, or when an SFP module is installed but has not established a link to an end node.
-
Page 35: Sd Card Slot
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide SD Card Slot All of the x610 Series Switches have an SD card slot for storing configuration files and AlliedWare Plus Operating System Software image files on an SD card (or SDHC card). See Figure 10. READY BUSY FAULT... -
Page 36: Port Leds
Chapter 1: Overview Port LEDs The following sections describe the 10/100/1000Base-T port, SFP, and SFP+ LEDs. On the non-PoE+ models, each port has two LEDs labeled L/A (link/ 10/100/1000 activity) and D/C (duplex mode/collisions). Figure 12 shows the port LEDs Base-T LEDs on the non-PoE+ models. -
Page 37: Table 6. Switch Base-T Led Descriptions
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Table 6 describes the LEDs for the Base-T ports. Table 6. Switch Base-T LED Descriptions Function State Description Link Status No link has been established between and Activity the port and the end node. Solid The port has established a link at Green... -
Page 38: Sfp And Sfp+ Leds
Figure 14, Figure 15, Figure 16, and Figure 17. LEDs For each SFP+ slot on the x610-24Ts/X, x610-24Ts/X-POE+, x610-48Ts/X, and x610-48Ts/X-POE+ switches there is one LINK/ACTIVITY LED, as shown in Figure 15 and Figure 17. The SFP+ LED definitions are given in Table 7 and the SFP LED definitions are given in Table 8. -
Page 39: Figure 16. Sfp Leds On X610-48Ts And X610-48Ts-Poe+ Switches
Figure 16. SFP LEDs on x610-48Ts and x610-48Ts-POE+ Switches SFP+ 1000 SFP LINK/ACT SFP+ LINK/ACT LEDs LEDs Figure 17. SFP and SFP+ LEDs on x610-48Ts/X and x610-48Ts/X-POE+ Switches Table 7. SFP+ Slot LED Descriptions Function State Description Link Status No link has been established between and Activity the port and the end node. -
Page 40: Table 8. Sfp Slot Led Descriptions
Chapter 1: Overview Table 8. SFP Slot LED Descriptions Function State Description Link Status No link has been established between and Activity the port and the end node. Solid The port has established a link at Green 1 Gbps. Flashing Packets are being received or Green transmitted at either 100Mbps or... -
Page 41: System Status Leds
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide System STATUS LEDs The system STATUS LEDs on the front panel display general status information. To locate these LEDs, see Figure 18. On the rear panel there is a single system STATUS LED, as shown in Figure 19. See Table 9 for a description of the system STATUS LEDs. - Page 42 Chapter 1: Overview Table 9. System STATUS LED Descriptions (Continued) State Description No optional redundant power supply is connected to the switch. Solid An optional redundant power supply is Green physically connected to the switch and may be powered on or off. The switch is not receiving power.
-
Page 43: Stack Leds
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide STACK LEDs The STACK LEDs display the link status of the VCStack stacking module and its two stacking ports. If a stacking module or the stack cables are not installed, all LEDs remain off. To locate the STACK LEDs, see Figure 20, and for a description of the STACK LEDs, see Table 10. - Page 44 Chapter 1: Overview Table 10. STACK LED Descriptions (Continued) State Description L/A 2 Stack Port 2 has not established a link to a stacking port on another VCStack stacking module. Solid Stack Port 2 has established a link to a Green stacking port on another VCStack stacking module.
-
Page 45: Secure Digital (Sd) Led
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Secure Digital (SD) LED All x610 Series Switches have one Secure Digital (SD) LED, shown in Figure 21 and defined in Table 11. READY BUSY FAULT Figure 21. SD Slot LED Table 11. -
Page 46: Terminal Port
Chapter 1: Overview Terminal Port The terminal port is used to establish a local (out-of-band) management session with the switch. You establish a local management session by connecting a terminal or a personal computer with a terminal emulation program to the port. The terminal port has an RJ-45 style connector. -
Page 47: Power Supplies
Series Layer 3 Gigabit Ethernet Switches Installation Guide Power Supplies The x610-24Ts-POE+, x610-24Ts/X-POE+, x610-48Ts-POE+ and x610-48Ts/X-POE+ switches are supplied with a factory installed blank panel on the power supply port. Either a 250W (AT-PWR250) power supply (PSU), 800W (AT-PWR800) PSU, shown in Figure 22, or a 1200W (AT-PWR1200) PSU, shown in Figure 23, can be installed in these switches. -
Page 48: Figure 23. At-Pwr1200 Power Supply
Chapter 1: Overview DC OUT FAULT 100-240VAC~ 16A MAX 2187 Figure 23. AT-PWR1200 Power Supply... -
Page 49: Redundant Power Supplies
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Redundant Power Supplies The Redundant Power Supply connector on an x610 Series switch rear panel can connect to an optional Redundant Power Supply (RPS), the AT-RPS3000. The RPS can provide power to the switch in the event of a failure of the switch’s internal power supply. - Page 50 Chapter 1: Overview The RPS can be the only source of PoE power for the switch or the RPS can boost the PoE power available from the primary power source, the power supply module installed in the switch. If the switch does not receive PoE power from its primary power supply, the available PoE power depends on the PoE rating of the associated power supply module in RPS.
-
Page 51: At-Lbm (Loop Back) Module
It provides the capability for a full line rate, non-blocking switching configuration when there are connections on the x610-48Ts/X and x610-48Ts/X-POE+ switches to all 44 copper ports, two SFP ports, and two SFP+ ports. If you need to configure the switch for stacking, you may install a VCStack stacking module in place of the AT-LBM Module. -
Page 52: Vcstack Stacking Module
Chapter 1: Overview VCStack Stacking Module A Virtual Chassis Stack (VCStack) is two or more separate Allied Telesis switches that are configured to operate as a single logical switch. The component switches are connected via VCStack stacking modules installed in each switch. -
Page 53: Ac Power Connector
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide AC Power Connector The x610 switches have a single AC power supply socket on the rear panel, which has autoswitch AC inputs. To power the switch on or off, connect or disconnect the power cord. For countries that require 100-125 VAC installations, the power cord plug provided with the AT-PWR1200 power supply has a 20 Amp, 125 V NEMA 5-20P plug. -
Page 54: Power Over Ethernet Plus (Poe+)
Chapter 1: Overview Power Over Ethernet Plus (PoE+) The following section applies to x610-24Ts-POE+, x610-24Ts/X-POE+, x610-48Ts-POE+ and x610-48Ts/X-POE+ Gigabit Ethernet switches only. The 10/100/1000Base-T ports on these switches feature Power over Ethernet (PoE), defined in the IEEE 802.3af standard, and Power over Ethernet Plus (PoE+), defined in the IEEE 802.3at standard. -
Page 55: Power Capacity
Power Capacity (AT-PWR1200) power supply (PSU) can be installed in the x610-24Ts- POE+, x610-24Ts/X-POE+, x610-48Ts-POE+ and x610-48Ts/X-POE+ switches. The model of PSU that is installed determines the maximum number of PoE+ ports that are supported on the switch. The following three tables show the maximum number of PoE+ and PoE ports supported on the switch, depending on the model of PSU installed. -
Page 56: Table 14. Poe+ Ports Supported With At-Pwr800 Power Supply Unit
480W Max 16 ports Max 24 ports x610-48Ts-POE+ 480W Max 16 ports Max 31 ports x610-48Ts/X-POE+ 480W Max 16 ports Max 31 ports Table 15. PoE+ Ports Supported With AT-PWR1200 Power Supply Unit IEEE 802.3af Available IEEE 802.3at Model... -
Page 57: Chapter 2: Virtual Chassis Stacking
Chapter 2 Virtual Chassis Stacking This chapter contains the following sections: “VCStack Introduction” on page 58 “Features of VCStacking” on page 58 “The Physical Stack” on page 59 “Resiliency Link” on page 60 “Resiliency Link Configurations via Switch Ports” on page 61 “Stack Formation”... -
Page 58: Vcstack Introduction
VCStack Introduction Virtual Chassis Stacking (VCStack™) is the name given to two or more separate Allied Telesis switches that are configured to operate as a single logical switch. The VCStack operates as a single device and is not perceived by end users, or the traffic itself, to be any more than a single network node. -
Page 59: The Physical Stack
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Depending on the switch types used, a stack can comprise from 2 to 8 The Physical individual stack members interconnected via high speed stacking links. A Stack stack always has a primary stack member called the stack master, and can contain up to 7 other stack members. -
Page 60: Resiliency Link
Chapter 2: Virtual Chassis Stacking Ring Configuration A virtual stack using x610 switches can comprise up to 8 stack members connected in a ring topology. Figure 30 shows a ring comprising 3 stacked x610 series switches with AT-StackXG stacking modules installed. Because an alternate path is provided between the stack members, this topology offers a very resilient configuration. -
Page 61: Resiliency Link Configurations Via Switch Ports
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Two resiliency-link configurations that connect to switch ports are shown Resiliency Link below. Figure 31 shows the resiliency link connecting in a ring topology, Configurations whilst Figure 32 shows the resiliency link connecting to its switch ports via via Switch Ports a network hub. -
Page 62: Stack Formation
Chapter 2: Virtual Chassis Stacking Stack Formation A VCStack always contains a master plus a number of stack members. To be part of a stack, a switch must connect to other potential stack members via dedicated stacking ports on the VCStack stacking module located in the rear of the switch. - Page 63 x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Note New switches are shipped with a Stack Member-ID of 1 and a priority of 128. If four such switches are created as a stack, the switch with the lowest MAC address will be selected to be the stack master (because all priority settings are 128).
-
Page 64: Figure 33. Stack And Status Leds
Chapter 2: Virtual Chassis Stacking Stack Member Identification When a switch becomes a member of a VCStack it is assigned a Stack Member-ID. Stack status information is displayed on the STACK and STATUS LEDs on the switch’s front panel, shown in Figure 33. STACK STATUS MSTR... -
Page 65: Connecting Switches Into A Stack
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Table 16. STACK LED Descriptions (Continued) State Description L/A 2 Stack Port 2 has not established a link to a stacking port on another VCStack stacking module. Solid Stack Port 2 has established a link to a Green stacking port on another VCStack stacking module. - Page 66 High Speed Stacking Cables (0.5 meter) - StackXG/0.5 High Speed Stacking Cables (1.0 meter) - StackXG/1 The specifications for SFP+ transceivers able to be installed in the AT-x6EM/XS2 stacking module can be found on our Allied Telesis web site at www.alliedtelesis.com. VCStack restrictions There are some restrictions to what products and connections you can combine in a single stack.
-
Page 67: Steps To Set Up A Vcstack
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide There are no set rules regarding the order in which stack configuration Steps to set up a tasks need to be carried out. However, these steps provide a guideline to VCStack help ensure that the stack creation process goes smoothly. - Page 68 Chapter 2: Virtual Chassis Stacking members should be green. Port LEDs that are off or flashing amber indicate that the stack is not operating correctly. The master or status LED will be green on the switch that is the stack master. 6.
-
Page 69: Steps To Replace A Stack Member
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide If you need to replace a stack member, use the following steps to achieve Steps to replace a a smooth transition. stack member 1. Configure the Stack ID on the replacement switch Prepare the replacement switch by configuring it with the same stack ID as the switch that you are replacing. - Page 70 Chapter 2: Virtual Chassis Stacking switches in a stack. This is possible even if mixed-mode stacking is disabled on x610 Series switches. For more information about stacking provisioning refer to the Stacking Introduction and Stacking Commands chapters in the AlliedWare Plus Operating System Software Reference from www.alliedtelesis.com.
-
Page 71: Chapter 3: Installing The Hardware
Chapter 3 Installing the Hardware This chapter provides procedures to install a x610 switch. The chapter contains the following sections: “Reviewing Safety Precautions” on page 72 “Unpacking a Switch” on page 75 “Installing the Power Cord Retaining Clip” on page 76 “Installing the Switches in an Equipment Rack”... -
Page 72: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document “Translated Safety Statements” posted on the Allied Telesis website at www.alliedtelesis.com. Warning: Class 1 Laser product. Warning: Do not stare into the laser beam. Warning: To prevent electric shock, do not remove the cover. No user-serviceable parts inside. - Page 73 x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide All Countries: Install product in accordance with local and National Electrical Codes. Circuit Overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of circuits might have on overcurrent protection and supply wiring.
- Page 74 Chapter 3: Installing the Hardware Warning: To reduce the risk of electric shock, the PoE ports on this product must not connect to cabling that is routed outside the building where this device is located. Caution: The unit does not contain field serviceable components.
-
Page 75: Unpacking A Switch
3. For a non-PoE switch, make sure the following components are included in your switch package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One non-PoE x610 Series Layer 3 Gigabit Ethernet Switch... -
Page 76: Installing The Power Cord Retaining Clip
Installing the Power Cord Retaining Clip This section applies to the fixed power supplies installed in the x610-24Ts, x610-24Ts/X, x610-48Ts, and x610-48Ts/X switches and to the AT-PWR250 and AT-PWR800 power supplies. Perform the following procedure to install the power cord retaining clip on the switches: 1. -
Page 77: Installing The Switches In An Equipment Rack
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Installing the Switches in an Equipment Rack Perform the following procedure to install each switch in a standard 19-inch rack: Note Steps 1, 2, and 3 are optional. These steps provide instructions on how to remove the snap-on plastic feet from the bottom of a switch. -
Page 78: Figure 37. Attaching Rack-Mount Brackets
Chapter 3: Installing the Hardware SF P REA DY BUS Y FAU LT CLASS LASER PRODU STA CK 100 0 MST R STA TUS FAU LT MAS TER PRE S CO NSO 2075 Figure 37. Attaching Rack-Mount Brackets 5. Mount the switch in a 19-inch rack using standard screws (not provided), as shown in Figure 38. -
Page 79: Vcstack Stacking Module Installation
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide VCStack Stacking Module Installation When you are preparing the x610 switches for a VCStack configuration, a Overview VCStack stacking module must be installed in the expansion slot on the rear panel of the unit. Two VCStack stacking modules are available: The AT-StackXG, shown in Figure 39, has two full-duplex, 12 Gbps stacking ports. -
Page 80: Preparation
Chapter 3: Installing the Hardware AT-StackXG must be installed. Review the following information before installing a VCStack stacking Preparation module: The AT-StackXG and AT-x6EM/XS2 stacking modules are hardware hot-swappable. You can install or replace a module while the switch is powered on. -
Page 81: Figure 41. Removing The Blank Panel From The Expansion Slot
Figure 41. Removing the Blank Panel from the Expansion Slot Note All x610 Series Layer 3 Switch models, except the x610-48Ts/X and x610-48Ts/X-POE+, are shipped from the factory with a blank panel installed in the rear panel expansion slot. The x610-48Ts/X and x610-48Ts/X-POE+ are shipped from the factory with an AT-LBM module installed. -
Page 82: Figure 42. Installing The At-Stackxg Stacking Module
Chapter 3: Installing the Hardware r is k o r v ic in S T A C R P S K IN G R E A D A T -L X A T - S ta 4 4 C P c k X G U C V R S ta c k... -
Page 83: Figure 44. Securing The At-Stackxg Stacking Module
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide r is k o r v ic in A T - L X A T - S ta 4 4 C P c k X G U C V R S T A C R P S K IN G R E A D... -
Page 84: Cabling An At-Stackxg Stacking Module
Chapter 3: Installing the Hardware 1. Remove the plastic protector from the connector at one end of the Cabling an stacking cable. AT-StackXG Stacking Module 1244 Figure 46. Removing the Plastic Protector 2. Connect the cable to either Stack Port 1 or Stack Port 2 on the stacking module and secure by tightening the two captive thumbscrews. -
Page 85: Cabling An At-X6Em/Xs2 Stacking Module
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide 1. Remove the dust plug from a transceiver slot on the switch, as shown Cabling an in Figure 47. AT-x6EM/XS2 Stacking Module r is k o r v ic in A T - x 6 A T - L X 4 4 C P E M / X... -
Page 86: Figure 49. Positioning The Sfp+ Transceiver Locking Handle
Chapter 3: Installing the Hardware 5. Verify that the handle on the SFP+ transceiver is in the upright position, as shown in Figure 49, to prevent inadvertently removing the transceiver. r is k o r v ic in A T - x 6 A T - L X E M / X 4 4 C P... -
Page 87: Figure 51. Connecting A Fiber Optic Cable To The Sfp+ Transceiver
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide r is k o r v ic in A T - x 6 A T - L X E M / X 4 4 C P U C V R S T A C R P S K IN G R E A D... - Page 88 Chapter 3: Installing the Hardware...
-
Page 89: Chapter 4: Cabling The Network Ports
Chapter 4 Cabling the Network Ports This chapter contains the instructions for attaching network cables to an x610 switch. The chapter contains the following sections: “Twisted Pair and Fiber Optic Specifications” on page 90 “Installing SFP and SFP+ Transceivers” on page 92 “Cabling the 10/100/1000Base-T and Fiber Optic Ports”... -
Page 90: Twisted Pair And Fiber Optic Specifications
Chapter 4: Cabling the Network Ports Twisted Pair and Fiber Optic Specifications Table 17 lists the cabling specifications for the 10/100/1000Base-T twisted Twisted Pair pair ports. Cable Specifications Table 17. Twisted Pair Cabling and Distances Maximum Speed Cable Type Operating Distance 10 Mbps Standard TIA/EIA 568-B-compliant... -
Page 91: Sfp And Sfp+ Transceiver Specifications
Series Layer 3 Gigabit Ethernet Switches Installation Guide The specifications for optional SFP and SFP+ transceivers can be found SFP and SFP+ on our Allied Telesis web site at www.alliedtelesis.com. Transceiver Specifications... -
Page 92: Installing Sfp And Sfp+ Transceivers
Chapter 4: Cabling the Network Ports Installing SFP and SFP+ Transceivers Review the following guidelines before installing an optional SFP or SFP+ transceiver in a switch: A transceiver can be hot-swapped; the switch can be powered on when you install it. However, you should always disconnect the cables first before removing a transceiver. -
Page 93: Figure 53. Installing A Transceiver
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide 2. Remove the transceiver from its shipping container and store the packaging material in a safe location. 3. Position the transceiver with the label facing up if installing in a top slot and with the label facing down if installing in a bottom slot. -
Page 94: Cabling The 10/100/1000Base-T And Fiber Optic Ports
Chapter 4: Cabling the Network Ports Cabling the 10/100/1000Base-T and Fiber Optic Ports Observe the following guidelines when connecting a twisted pair or fiber optic cable to a port on the switch: The connector on the cable should fit snugly into the port on the switch. -
Page 95: Powering On A Switch With A Dc At-Pwr250 Power Supply Module
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Powering on a Switch with a DC AT-PWR250 Power Supply Module To power on a switch with a DC AT-PWR250 Power Supply Module, perform the following procedure: Warning As a safety precaution, install a circuit breaker with a minimum value of 15 Amps between the equipment and the DC power source. -
Page 96: Figure 54. Dc Terminal Block On The Dc At-Pwr250 Power Supply Module
Chapter 4: Cabling the Network Ports 40-60VDC DC OUT FAULT 2205 +48 VDC Positive Ground -48 VDC Negative Terminal Terminal Terminal Figure 54. DC Terminal Block on the DC AT-PWR250 Power Supply Module 4. With a 14-gauge wire-stripping tool, strip the three wires in the tray cable coming from the DC input power source to 8mm ±... -
Page 97: Figure 56. Inserting Wires Into A Dc Terminal Block
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Warning When installing this equipment, always ensure that the power supply ground connection is installed first and disconnected last. 4 0 - 6 0 V D C O U T P U T P F A U L O W E... - Page 98 Chapter 4: Cabling the Network Ports 10. Connect the supply-cable wires to the circuit breaker. 11. Energize the circuit breaker. 12. Turn the power supply module’s On/Off switch to On. 13. Start a local management session on the unit by performing the procedure “Starting a Local Management Session”...
-
Page 99: Powering On A Switch With An Ac Power Supply Module
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Powering on a Switch with an AC Power Supply Module To power on a switch with an AC Power Supply Module, perform the following procedure: 1. Position the power cord retaining clip in the up position, as shown in Figure 57. -
Page 100: Figure 59. 100-125 Vac 125 V Nema 5-20 Plug And Receptacle
Chapter 4: Cabling the Network Ports Note For countries that require 100-125 VAC installations, the power cord plug provided with the AT-PWR1200 power supply has a 20 Amp, 125 V NEMA 5-20P plug. This plug is only compatible with a NEMA 5-20R receptacle. -
Page 101: Starting A Local Management Session
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide The following procedure describes how to connect an RJ-45 cable to an Starting a Local x610 switch. For information about how to log onto the AlliedWare Plus Management Operating System Software, see the AlliedWare Plus Operating System Session Software Reference Guide. -
Page 102: Warranty Registration
Chapter 4: Cabling the Network Ports Warranty Registration For warranty information and registration, go to the Allied Telesis web site at www.alliedtelesis.com/support/warranty. -
Page 103: Chapter 5: Troubleshooting
“Issues with Virtual Stacking Chassis Configuration” on page 112 Note If you are unable to resolve the problem after following the instructions in this chapter, contact Allied Telesis Technical Support for assistance. Refer to “Contacting Allied Telesis” on page 18 for contact information. -
Page 104: Power Led Is Off
Chapter 5: Troubleshooting Power LED is Off Check the PWR LED on the front of the switch. If the LED is off, indicating that the unit is not receiving power, do the following: Make sure the power cord is securely connected to the power source and to the AC connector on the rear panel of the switch. -
Page 105: Twisted Pair Port Link Led Is Off
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Twisted Pair Port Link LED is Off When a twisted pair port on the switch is connected to a properly operating end node, the Link LED for the port should be on. If a Link LED is off, do the following: Note A 1000Base-T connection can take from five to ten seconds to... -
Page 106: Sfp Or Sfp+ Led Is Off
Chapter 5: Troubleshooting SFP or SFP+ LED is Off When a fiber optic port on the switch is connected to a properly operating end node, the Link LED for the port should be on. If a Link LED is off, do the following: Verify that the end node connected to the port is powered ON and is operating properly. -
Page 107: Transceiver Is Installed But The Status Is "Not Present
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Transceiver is Installed but the Status is “Not Present” If a SFP or SFP+ transceiver is installed in a transceiver slot but the Uplink Information menu in the AlliedWare Plus Operating System Software interface displays “Not Present”... -
Page 108: System Fault Led Is Blinking
Chapter 5: Troubleshooting System Fault LED is Blinking A blinking FAULT LED indicates that the switch is updating the active boot configuration file or a new version of the operating system software is in the process of being downloaded to the switch. The LED stops blinking after the switch has completed updating the boot configuration file or downloading the operating system software. -
Page 109: System Fault Led Is Steadily On
If the FAULT LED remains ON, download a new version of the switch’s operating system software. For instructions, refer to the AlliedWare Plus Operating System Software Reference Guide. Note If the FAULT LED remains steadily on, contact Allied Telesis Technical Support for assistance. See “Contacting Allied Telesis” on page 18. -
Page 110: Cannot Establish A Local (Out-Of-Band) Management Session
Chapter 5: Troubleshooting Cannot Establish a Local (Out-of-Band) Management Session If you are unable to establish a local (out-of-band) management session with the switch through the terminal port on the front panel, do the following: Check that the RJ-45 serial management cable is securely connected to the serial terminal port on the switch and to the RS-232 port on the terminal or personal computer. -
Page 111: Switch Functions Intermittently
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Switch Functions Intermittently If a switch functions intermittently, check the system hardware status through the management interface: Note the current voltage for the power supply compared to the optimum rating. Verify that the system temperature is within the operating range. -
Page 112: Issues With Virtual Stacking Chassis Configuration
Chapter 5: Troubleshooting Issues with Virtual Stacking Chassis Configuration For information on issues with stacking, refer to the Allied Telesis Inc. website (www.alliedtelesis.com) for the Overview of Virtual Chassis Stacking (VCS) and the Virtual Chassis Stacking section of the AlliedWare... -
Page 113: Appendix A: Technical Specifications
(1.72 in. x 17.34 in. x 16.5 in.) x610-48Ts 44 mm x 440 mm x 419 mm (1.72 in. x 17.34 in. x 16.5 in.) x610-48Ts/X 44 mm x 440 mm x 419 mm (1.72 in. x 17.34 in. x 16.5 in.) x610-24Ts-POE+ 44 mm x 440 mm x 419 mm (1.72 in. -
Page 114: Environmental Specifications
480 W 575 W 95 W 780 W 875 W x610-48Ts-POE+ x610-48Ts/X-POE+ 100 W 100 W 100 W 480 W 580 W 100 W 780 W 880 W Input Voltage: AC Input (Non-POE Models)100-240V AC, 2.0 A maximum, 50/60 Hz... -
Page 115: Certifications
EN60950-1 (TUV), EN60825-1 (TUV), UL 60950-1 ( ), CSA-C22-2 No. 60950-1 ( Quality and Reliability (MTBF): x610-24Ts 80,000 hrs. x610-24Ts/X 80,000 hrs. x610-48Ts 70,000 hrs. x610-48Ts/X 60,000 hrs. x610-24Ts-POE+ 160,000 hrs. x610-24Ts/X-POE+ 150,000 hrs. x610-48Ts-POE+ 120,000 hrs. x610-48Ts/X-POE+ 120,000 hrs. -
Page 116: Figure 61. Rj-45 Connector And Port Pin Layout
Appendix A: Technical Specifications RJ-45 Twisted Pair Port Pinouts Figure 61 illustrates the pin layout of an RJ-45 connector and port. Pin 1 Figure 61. RJ-45 Connector and Port Pin Layout Table 19 lists the pin signal definitions when a port is operating in the MDI configuration at 10 or 100 Mbps. -
Page 117: Table 21. Pin Signals - 1000 Mbps
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Table 21 lists the pin signal definitions when a port operating at 1000 Mbps. Table 21. Pin Signals - 1000 Mbps Pinout Pair Pair 1 + Pair 1 - Pair 2 + Pair 3 + Pair 3 - Pair 2 -... -
Page 118: Figure 62. At-Rps3000 21-Pin Connector Layout
Appendix A: Technical Specifications RJ-45 Style Serial Terminal Port Pinouts Table 22 lists the pin signal definitions on the RJ-45 style serial terminal port. Table 22. RJ-45 Style Serial Terminal Port Pin Signals Signal Request to Send Data Terminal Ready Transmit Data Data Carrier Detect Ground... -
Page 119: Table 23. At-Rps3000 21-Pin Connector Pinout Definitions
x610 Series Layer 3 Gigabit Ethernet Switches Installation Guide Table 23 lists the RPS 21-pin D-combo port and connector pinout definitions. Table 23. AT-RPS3000 21-Pin Connector Pinout Definitions Definition 12V Return 12V Power Contact 56V Power Contact (for PoE Ready port only) 56V Return (for PoE Ready port only) 12V Positive Remote Sense Reserved... - Page 120 Appendix A: Technical Specifications...
