Allied Telesis 4000 Series Release Note
Allied Telesis 4000 Series Release Note

Allied Telesis 4000 Series Release Note

Software maintenance release note sb275a05

Advertisement

Quick Links

Software Maintenance Release Note
Software Version sb275a05
For SwitchBlade 4000 Series Switches
Introduction
This software maintenance release note lists the issues addressed and
enhancements made in maintenance version sb275a05 for Software Release
2.7.5A on existing models of SwitchBlade series switches. Release file details
are listed in
Table
1.
Table 1: Release file details for release sb275a05
Maintenance Release Date
Compressed Release File Name
Compressed Release File Size
GUI Resource File Name
This maintenance release note should be read in conjunction with the
following:
the documentation you received with Software Release 2.7.5A
the SwitchBlade Document Set for Software Release 2.7.3 (Document
Number C613-03100-00 REV A), available from:
www.alliedtelesis.co.nz/documentation/documentation.html
Caution: Using a software maintenance version for the wrong model may cause
unpredictable results, including disruption to the network.
Information in this release note is subject to change without notice and does not
represent a commitment on the part of Allied Telesis Inc. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesis Inc. can not
accept any type of liability for errors in, or omissions arising from the use of this
information.
7 February 2007
sb275a05.rez
3764560
d_sb8e29.rsc (8-slot chassis)
d_sb4e29.rsc (4-slot chassis)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allied Telesis 4000 Series

  • Page 1 Information in this release note is subject to change without notice and does not represent a commitment on the part of Allied Telesis Inc. While every effort has been made to ensure that the information contained within this document and the features and changes described are accurate, Allied Telesis Inc.
  • Page 2 Enabling and installing this Release Some of the issues addressed in this Maintenance Release Note include a level number. This number reflects the importance of the issue that has been resolved. The levels are: Level 1 Level 2 Level 3 Level 4 Enabling and installing this Release To use this maintenance release you must have a base release license for...
  • Page 3 Software Version sb275a05 Features in sb275a05 Software maintenance version sb275a05 includes all resolved issues and enhancements in earlier 2.7.5A versions, and the resolved issues and enhancements in the following tables. Level 1 No level one issues Level 2 Module CR00009347 CR00010874 IP Gateway OSPF...
  • Page 4 Features in sb275a05 Module IP Gateway CR00015071 CR00015132 Switch Switch CR00015190 CR00015697 Switch Level 3 Module CR00011444 Asyn DHCP CR00012858 Level 4 No level four issues Level Routing over a PPP interface could fail if the switch had a default route out an Ethernet port.
  • Page 5 Software Version sb275a05 Enhancements Module CR00013351 IGMP snooping, EPSR, RSTP CR00014222 IGMP snooping, Switch, VLAN Version sb275a05 C613-10464-00 Rev H Level A new feature has been added to IGMP snooping, to minimise loss of multicast data after a topology change on networks that use EPSR or spanning tree (STP, RSTP, or MSTP) for loop protection and IGMP snooping.
  • Page 6 Features in sb275a04 Features in sb275a04 Software maintenance version sb275a04 includes all resolved issues and enhancements in earlier 2.7.5A versions, and the resolved issues and enhancements in the following tables. Level 1 No level one issues Level 2 Module IP Gateway CR00007522 CR00012896 CR00009026...
  • Page 7 Software Version sb275a05 Module OSPF CR00011585 OSPF CR00012067 CR00012606 CR00012783 VLAN Switch CR00013178 CR00013275 Firewall CR00013380 IP Gateway IP Gateway CR00013598 CR00014044 IGMP Version sb275a05 C613-10464-00 Rev H Level Adding the same OSPF stub or host twice caused OSPF to suspend its operation, causing neighbour relationships to eventually fail.
  • Page 8 Features in sb275a04 Level 3 Module CR00000133 CR00008167 CR00002589 CR00011829 CR00009817 Ping CR00010183 OSPF CR00010184 OSPF CR00011652 CR00012130 IP Gateway CR00012427 Logging CR00002887 CR00012947 Level Messages in the permanent log were lost after changing the queue length for the permanent log. This issue has been resolved.
  • Page 9 Software Version sb275a05 Module Firewall CR00013048 CR00014021 Switch Level 4 Module CR00002394 IP Gateway OSPF CR00008006 CR00010399 IP Gateway CR00010540 OSPF CR00010584 CR00011743 Core, GUI CR00012192 Core, Utility Version sb275a05 C613-10464-00 Rev H Level When IP NAT or firewall NAT was used, the switch sometimes generated ICMP messages that specified the wrong source IP address.
  • Page 10 Features in sb275a04 Module IP Gateway, CR00012774 CR00012946 Core CR00013332 CR00013334 CR00013336 Core, NVS, TCP, Switch CR00013442 Level In an unusual network configuration where the IP subnet on one interface was a subset of that on another interface, it was possible for the results of a trace route to show erroneous information.
  • Page 11 Software Version sb275a05 Enhancements Module CR00013349 IP Gateway IP Gateway CR00013444 Features in sb275a03 Software maintenance version sb275a03 was not released. Version sb275a05 C613-10464-00 Rev H Level It is now possible to specify a timeout value when enabling IP debugging. After the timeout expires, IP debugging will be automatically disabled.
  • Page 12 Features in sb275a02 Features in sb275a02 Software maintenance version sb275a02 includes all resolved issues and enhancements in earlier 2.7.5A versions, and the resolved issues and enhancements in the following tables. Level 1 No level one issues Level 2 Module IP Gateway CR00006503 CR00012264 IP Gateway...
  • Page 13 Software Version sb275a05 Module IP Gateway, CR00012726 VLAN, VRRP Switch, VLAN, CR00012782 VRRP Switch CR00012961 Version sb275a05 C613-10464-00 Rev H Level Previously, if a VLAN had been configured for use as the primary interface for a VRID within VRRP, it was possible to delete the VLAN’s IP interface. Also, if the IP address of the VLAN was changed (by using the command set ip), the priority of the VRID was not recalculated.
  • Page 14 Features in sb275a02 Level 3 Module CR00009379 Appletalk CR00010377 Switch CR00010798 File, Install CR00011308 Switch CR00011774 CR00011849 Alarm CR00012323 Switch, VLAN CR00012609 IP Gateway, Switch, VLAN CR00012651 IP Gateway Level When the switch was using AppleTalk, it occasionally failed to process traffic.
  • Page 15 Software Version sb275a05 Module File CR00012747 CR00012786 IP Gateway Level 4 No level four issues Enhancements Module Core, CURE, CR00012616 File, Show Version sb275a05 C613-10464-00 Rev H Level The upload command (upload server=x.x.x.x file=filename.ext) did not allow files with KEY, CER or CSR extensions to be uploaded from the switch.
  • Page 16 Features in sb275a01 Features in sb275a01 Software maintenance release sb275a01.rez includes the resolved issues and enhancements in the following tables. Level 1 Module CR00004954 Switch CR00010870 LACP CR00011417 SYSR CR00011601 HealthCheck Level 2 Module CR00005408 IGMP CR00008791 PIM4 CR00009693 GUI Agent CR00010029 SYSR Level...
  • Page 17 Software Version sb275a05 Module CR00010052 Switch CR00010765 SYSR CR00010996 Port Authentication CR00011002 CR00011247 GUI Agent CR00011273 SYSR CR00011337 Environment Monitoring CR00011485 SYSR CR00011600 GUI Agent CR00011822 HTTP Server CR00011880 Version sb275a05 C613-10464-00 Rev H Level The maximum number of IP interfaces that can be defined on a line card switch instance is 60.
  • Page 18 Features in sb275a01 Level 3 Module CR00007863 IPv4 ICMP CR00011316 Operations CR00011339 Port Trunking CR00011480 DHCPv4 Server Level 4 Module CR00011127 SYSLOG CR00011184 HealthCheck CR00011651 Board Hotswap Enhancements Module CR00011621 SYSR Level Previously, SwitchBlade v2 linecards did not generate an ICMP redirect message in response to the first ICMP request they received.
  • Page 19 Software Version sb275a05 IGMP Snooping Query Solicitation (CR00013351) Query solicitation minimises loss of multicast data after a topology change on networks that use EPSR or spanning tree (STP, RSTP, or MSTP) for loop protection and IGMP snooping. When IGMP snooping is enabled on a VLAN, and EPSR or Spanning Tree (STP, RSTP, or MSTP) changes the underlying link layer topology of that VLAN, this can interrupt multicast data flow for a significant length of time.
  • Page 20 IGMP Snooping Query Solicitation (CR00013351) IGMP Snooping -------------------------------------------------------------------------- Status ... Enabled Disabled All-groups ports ... None Vlan Name (vlan id) ... default (1) Fast Leave ... Off Query Solicitation ... Off Group List ... No group memberships. -------------------------------------------------------------------------- Changes to IGMP Snooping Fast Leave Command Syntax The command syntax for the Fast Leave feature has also been changed, to make it more like the syntax for the query solicitation feature.
  • Page 21: Extended Monitoring Of Cpu Utilisation

    Software Version sb275a05 Extended Monitoring of CPU Utilisation (CR00012616) This Software Version includes a new feature for monitoring CPU utilisation. You can now set the switch to capture data about which specific functions the CPU is executing, and what level of instantaneous usage the CPU is experiencing.
  • Page 22 Extended Monitoring of CPU Utilisation (CR00012616) Figure 1: Example output from the show cpu extended command CPU Utilisation ( as a percentage ) ---------------------------------------- Maximum since router restarted ... 100 Maximum over last 5 minutes ... 100 Average since router restarted ... 5 Average over last 5 minutes ...

This manual is also suitable for:

Switchblade 4000 series
