Remote switching control

The port switching functions of the AdderView CATxIP
5000 unit can be remotely controlled by an RS232 link to
the port on the rear panel.
OPTIONS
The sending device must use the following RS232
communication settings:
Baud rate: 19200 bps
Data bits: 8
Parity: None
Stop bits: 1
No handshaking is implemented, however, valid command characters will be
echoed back to the sending device.
Note: You must ensure that the AdderView CATxIP 5000 unit has it Options
serial ports set to 'Sync Units'. This setting (together with the baud rate
selection) can be made either via the
The value of the byte received via the serial link determines which computer port
should be linked through to the user port. The table given here summarises the
valid control codes:
1 2 3
Local user
10 11 12
REMOTE
CONTROL
local or global user configuration menus.
Host computer port/channel
4 5 6 7 8 9 10
13 14 15 16 17 18 19
Cable from serial
control device
11 12 13 14 15 16
1A 1B 1C 1D 1E 1F
AdderView CATxIP 5000
rear panel
O P
T I O
N S
5 V
4 . 0
A
0 (video off)
71
1 6
1
1 2
C O
1
M P
U T
17
