- Page 1 AdderView DDX User Guide Experts in Switching Connectivity Solutions Solutions...
-
Page 2: Table Of Contents
Contents Introduction Configuration Accessing DDX Matrix ..................14 Welcome ........................2 Using DDX Matrix .....................15 Access permissions ..................2 The Dashboard page ...................15 Port designations ....................3 Quick guide to creating a new installation ..........16 Supplied items .......................4 The Control page ..................17 Optional extras .....................6 The Configure pages ...................18 Installation Configure >... -
Page 3: Welcome
WELCOME If required, computers and consoles can be individually Thank you for choosing the AdderView DDX system. This adaptive system makes sharing numerous host computers among multiple users straightforward and flexible. connected in order to take advantage of the DDX extender properties without the switching. -
Page 4: Port Designations
Port designations By default the DDX switch provides 10 user console ports on its front panel and 20 For more details, please see Reallocating ports. computer ports along its rear panel, however, these designations are not fixed. If your installation requires a greater number of computers or has a need for more user consoles, you can alter the allocation of these standard ports to suit: Ports 21 to 23 can be reallocated as computer... -
Page 5: Supplied Items
SUPPLIED ITEMS DDX switch package AdderView DDX switch Power adapter with locking connector and country- specific power cord Information wallet containing: Four self-adhesive rubber feet Safety document 19” rack mount brackets and four screws... - Page 6 DDX-USR package DDX-CAM DisplayPort option DDX-USR module DDX-CAM module with USB and DisplayPort connections Part number: DDX-CAM-DP DDX-CAM DVI option DDX-CAM module with USB and DVI-D connections Part number: DDX-CAM-DVI Power adapter with locking connector and country- specific power cord Information wallet containing: Four self-adhesive rubber feet...
-
Page 7: Optional Extras
OPTIONAL EXTRAS USB cable 2m (type A to B) Audio cable 3m (3.5mm stereo jacks) Part number: VSC24 Part number: VSC22 50m CAT7 cable Part number: VSCAT7-50 Replacement power adapter with locking connector for DDX-USR module Part number: PSU-IEC-12VDC-1.5A Country-specific power cords CAB-IEC-AUS (Australia) CAB-IEC-EURO (Central Europe) CAB-IEC-UK (United Kingdom) -
Page 8: Installation
LOCATIONS Please consider the following important points when planning the position of the AdderView DDX modules: • If used, position the DDX switch in a central position that serves the host computer systems and user modules without exceeding the maximum link lengths. It will also require a source of mains power. -
Page 9: Connections
CONNECTIONS Computer connections: USB Connections do not need to be carried out in the order given within this guide, however, where possible connect the power in as a final step. Connections are split into the Each DDX-CAM module requires a single USB connection to the computer. This following three areas: provides essential power for the DDX-CAM module in addition to the USB signals. -
Page 10: Switch Connections: Computer Links
Switch connections: Computer links Switch connections: Network link The host computer links are made to the sockets on the rear panel of the DDX switch. All system configuration is carried out via an Ethernet link, allowing adjustments to be made by authorized admin users located next to the DDX unit, or anywhere. The auto- To connect a computer link sensing network port can determine between 10, 100Mbps or 1Gbps links and can also 1 Connect the CAT7 cable from the... -
Page 11: Switch Connections: Power
Switch connections: Power Each DDX switch is supplied with a single power adapter but offers the facility to use To disconnect the power adapter a second input in order to provide operational redundancy. The DDX unit can operate 1 Isolate the power adapter from the perfectly well from a single power adapter operating alone. -
Page 12: Console Connections: Video
Console connections: Video Console connections: USB A Single Link DVI-D port is provided on the rear panel of the user module. The DDX-USR module contains a USB hub that can support up to four v1.1 or v2.0 USB devices (in any combination). All four USB sockets, two on the front panel and two on The DDX-USR module supports one video display with pixel clocks up to 165MHz the rear, are identical in operation. -
Page 13: Console Connections: Audio
Console connections: Audio Console connections: Data link The DDX-USR module supports stereo speakers, headphones and also a microphone Each DDX-USR module is linked via a CATx cable either to a central DDX switch port. All audio devices are presented at the linked host computer as USB audio devices. module or directly to a DDX-CAM module (for a single system installation). -
Page 14: Console Connections: Power
Console connections: Power There is no on/off switch on the DDX-USR module, so operation begins as soon as power is applied. The supplied power adapter uses a locking-type plug to help prevent accidental disconnections; please follow the instructions given right whenever disconnecting a power adapter. -
Page 15: Configuration
Configuration ACCESSING DDX MATRIX DDX switches are configured via their network connections using an intuitive browser- based application, called DDX Matrix. This secure, password protected application is accessible by any authorized user, located anywhere. To access DDX Matrix 1 Use a computer that is directly or indirectly (i.e. via a network switch) connected to the DDX switch. -
Page 16: Using Ddx Matrix
USING DDX MATRIX The Dashboard page Once you have successfully logged in, DDX Matrix will show the dashboard page to provide a general overview of your DDX installation. You can also re-display this page by clicking the Dashboard entry in the menu: Information and options are displayed within the main section of the page. -
Page 17: Quick Guide To Creating A New Installation
Quick guide to creating a new installation When creating a new DDX installation there are various configuration tasks that need to be completed within DDX Matrix. This page provides a recommended ‘to do list’ of the stages that you need to perform. Primary tasks •... -
Page 18: The Control Page
The Control page The Control page provides a Connection map that allows the admin user to view and affect how consoles are connected to the various computers. This page is particularly useful when managing video-only installations. To connect a console 1 Click the down arrow on the console entry to reveal the list of computers that it is authorized to access. -
Page 19: The Configure Pages
The Configure pages The Configure menu option expands when clicked to reveal three sub-sections: • Central Switch - settings related directly to the DDX switch. • Consoles - settings related to the DDX-USR modules and their connected peripherals. • Computers - settings related to the DDX-CAM modules and their host computers. - Page 20 Central Switch > OSD Settings Central Switch > Manage EDIDs Add EDID Options related to the on screen display are This page lists the EDID (Extended Display Identification Data) If additional EDID definitions are required for presented in this section: profiles that are currently available: your installation, you can clone new definitions from connected video displays and add these to...
-
Page 21: Configure > Consoles
Configure > Consoles A Console is a collective term for a set of peripheral devices arranged around one or more DDX-USR modules. This page lists all registered consoles: arrows allow you to reorder the list in ascending or descending order according to the entries within any column In addition to the Name and Description, other columns provide the following details and options for each console entry:... - Page 22 Configure > Consoles > Edit an entry Click on an entry within the Configure > Consoles list to display this page. Here you can edit the configuration details for a chosen console. Edit • Name - the main identifier for the console. •...
-
Page 23: Configure > Consoles > Receivers
Configure > Consoles > Receivers At the heart of each console (the collective term for a set of peripherals connected to the DDX system) is a receiver called a DDX-USR module. arrows allow you to reorder the list in ascending or descending order according to the entries within any column This page shows various details for each DDX-USR module: •... -
Page 24: Configure > Computers
Configure > Computers This page lists the computer systems that are connected to the DDX switch unit via individual DDX-CAM modules: arrows allow you to reorder the list in ascending or descending order according to the entries within any column Add new Click the [+] icon to begin adding a new computer, either before or after connecting the DDX-CAM... - Page 25 Configure > Computers > Edit an entry This page allows you to edit the configuration details for a chosen computer. Edit • Name - the main identifier for the computer. • Description - a further opportunity to add more information about the computer.
-
Page 26: Configure > Computers > Transmitters
Configure > Computers > Transmitters Each computer connects to a DDX-CAM transmitter module. This page lists each DDX-CAM module and their key details: arrows allow you to reorder the list in ascending or descending order according to the entries within any column This page lists various details for each DDX-CAM module: •... -
Page 27: Reallocating Ports
Reallocating ports By default the DDX switch provides 10 user console ports on its front panel and 20 computer ports along its rear panel, however, these designations are not fixed. If your installation requires a greater number of computers or has a need for more user consoles, you can alter the allocation of these standard ports to suit: •... -
Page 28: The Users Page
The Users page This page lists all registered users and allows the admin user to add, edit and delete entries, as required. Note: When changes are made to user details, you are recommended to make a backup file. Add new Click the [+] icon to begin adding a new user. -
Page 29: The Maintenance Pages
The Maintenance pages The Maintenance section contains three pages: Diagnostics, System Operations and Settings. Maintenance > Diagnostics This page provides important feedback on power inputs (and switch Temperatures). The temperature information is displayed only when the Maintenance > Settings > Web UI Mode is set to Advanced. -
Page 30: Maintenance > System Operations
Maintenance > System Operations This page provides a selection of important system operations that may be required at various times. Recovering an unresponsive transmitter or receiver If a firmware upgrade to a transmitter or receiver has failed, the unit may become unresponsive. -
Page 31: Maintenance > Settings
Maintenance > Settings This page provides options related to the user interface. When you make a change, you need to click the Update button to save it. Web UI Mode When this option is set to Advanced, extra details are shown on certain pages, such as: •... -
Page 32: Resetting And Recovering
RESETTING AND RECOVERING There may be rare occasions when the main switch or a module needs to be given a hard reset. The DDX switch and DDX-USR module both have concealed reset buttons for this purpose. You need to use a narrow implement (e.g. -
Page 33: Operation
Operation The DDX system is designed to be transparent in operation. A simple OSD (On Screen Display) interface allows each user to view and select from the available host computers. VIEWING THE OSD Choosing a computer To view the OSD, either: To choose a computer using the mouse 1 Display the OSD from your console using either of the methods shown left. -
Page 34: Using Audio
USING AUDIO The DDX system fully supports stereo audio, with all audio devices being presented at the linked host computer as USB audio devices. There are slight differences in audio operation between DDX devices acting in a simple extender arrangement (without the use of a DDX switch) and a full DDX matrix installation. -
Page 35: Indicators
INDICATORS The DDX switches, the DDX-CAM and DDX-USR modules contain various indicators to provide you with status information. DDX switch - Green and amber network status indicators DDX switch - Red front panel status indicators The green and amber status indicators on the network link port provide further The red status indicators on DDX switch front panels provide various key power and operation feedback: status information:... - Page 36 DDX-USR module - Green and amber status indicators DDX-CAM module - Green and amber status indicators The green and amber indicators on the link port of each DDX-USR (console/ The green and amber indicators on the link port of each DDX-CAM (computer) user) module provide the following status information: module provide the following status information: Amber...
-
Page 37: Further Information
- Link cable interference protection • Online solutions and updates – www.adder.com/support • Appendix 2 - Firmware upgrades for basic extender installations Check the Support section of the adder.com website for the latest solutions and • Safety information firmware updates. • Warranty •... -
Page 38: Appendix 1 - Link Cable Interference Protection
APPENDIX 1 - LINK CABLE INTERFERENCE PROTECTION While the Category rating (e.g. CAT 5e, CAT 6a, CAT 7, etc.) determines the electrical performance of a cable, another vital part of the overall cable specification is its protection from interference. As cabling distances and data rates increase, so too does the susceptibility to interference, from both external and internal sources. -
Page 39: Appendix 2 - Firmware Upgrades For Basic Extender Installations
APPENDIX 2 - FIRMWARE UPGRADES FOR BASIC EXTENDER INSTALLATIONS Extender systems (or individual DDX-USR units) can be upgraded using a USB stick if required. This is carried out as follows: 1 Connect the DDX-USR to a compatible display and keyboard; optionally connect to a DDX-CAM module using a CATx data cable to upgrade it at the same time. -
Page 40: Warranty And Safety Information
• No user serviceable parts within power adapter(s) - do not dismantle. Adder will replace or repair it free of charge. No liability can be accepted for damage due • Plug the power adapter(s) into socket outlets close to the module that they are to misuse or circumstances outside Adder’s control. -
Page 41: Radio Frequency Energy
RADIO FREQUENCY ENERGY A Category 5e (or better) twisted pair cable must be used to connect the units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. All cables used with this equipment must be shielded in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. - Page 42 Web: www.adder.com Contact: www.adder.com/contact-details Support: www.adder.com/support © 2015 Adder Technology Limited All trademarks are acknowledged. www.ctxd.com Documentation by: Part No. MAN-DDX-ADDER • Release 1.1a...
- Page 43 Index Sync Tx/Rx Firmware 29 System Default EDID 18 Access permissions 2 Dashboard page 15 IEC connector 10 Password System Operations 29 default 14 Add EDID 19 Data link Ignore Firmware Mismatch 18 Audio 33 console 12 Indicators 34 PiMF 37 Audio connections Data link connection modules 35...
