APPENDIX C: HARDWARE DIP SWITCHES (on rear panel)
Hard Switch 1
123456 78
xxxxxx xx
****** *.) Parallel Board Jumper Status (Must be 0 when using
****** *
****** .)) 1=Parallel Board Detected
******
*****.)))0=No Parity, 1=Enable Parity (COM1)
****.))))0=Odd Parity, 1=Even Parity (COM1)
***.)))))0=8 Data Bits, 1=7 Data Bits (COM1)
**.)))))))),
*.)))))))),*
.)))))))),**
000
100
010
110
001
101
011
111
90
firmware versions 1.65 and higher)
Bits per Second (COM1)
300 bps
600 bps
1200 bps
2400 bps
4800 bps
9600 bps
19200 bps
38400 bps
