TDZ 2000 GL1/ExtremeZ GL1
System Setup
July 1998
DHA027110

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDZ 2000 GL1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intergraph TDZ 2000 GL1

Summary of Contents for Intergraph TDZ 2000 GL1

  • Page 1 TDZ 2000 GL1/ExtremeZ GL1 System Setup July 1998 DHA027110...
  • Page 2 Notice Information in this document is subject to change without notice and should not be considered a commitment by Intergraph Computer Systems. Intergraph Computer Systems shall not be liable for technical or editorial errors in, or omissions from, this document. Intergraph Computer Systems shall not be liable for incidental or consequential damages resulting from the furnishing or use of this document.
  • Page 3 Notes This device is designed and manufactured to comply with approved safety standards for information processing and business equipment. Read all operating instructions before using this device. Keep these instructions for future reference. Follow all warnings on the device or in the operating instructions.

  • Page 5: Table Of Contents

    Learning About System Ergonomics ................... xi Customer Support ....................... xi Hardware and Software Support Services .............. xi World Wide Web ....................xi Intergraph Bulletin Board Service ................. xi FAXLink......................xii Telephone ......................xii More Support Options ..................xiii 1 Setting Up the Hardware ....................1 Unpacking the System ......................
  • Page 6 Configuring a Modem......................24 Changing Hard Disk Drive Letters (Windows NT) ............. 25 Changing Virtual Memory Settings (Windows NT) ............26 Getting Operating System Updates..................26 4 Configuring the BIOS ....................27 Overview ........................... 28 Starting BIOS Setup ......................28 Using BIOS Setup......................
  • Page 7 System Power ........................62 System Boot........................62 Sound ..........................65 Video..........................66 Miscellaneous Hardware ....................66 Network..........................67 7 Installing System Software.................... 69 Before You Begin ......................70 System Software Products....................70 Drivers and Applications for ExtremeZ Systems ..............72 Installing Windows NT Workstation 4.0 ................
  • Page 8 viii...

  • Page 9: Preface

    Preface TDZ 2000 GL1/ExtremeZ GL1 System Setup describes setting up and configuring your TDZ 2000 GL1 or ExtremeZ GL1 System system for use. This document also provides information on operating the system, troubleshooting, and reinstalling system software. NOTE If you have an ExtremeZ workstation, see the ExtremeZ Customer Welcome Letter first. The ExtremeZ Customer Welcome Letter provides step-by-step instructions for initial setup of an ExtremeZ workstation.

  • Page 10: Finding Operating System Information

    An online introduction to your new system is provided in the System Introduction, which covers subjects such as the following: System features Basic system controls and connections Intergraph customer support You can display the System Introduction by using the InterSite Welcome dialog or by opening the file on your system.

  • Page 11: Learning About System Ergonomics

    On these pages, you can get news and product information, technical support information, software updates and fixes, and more. Intergraph Bulletin Board Service On the Intergraph Bulletin Board Service (IBBS), you can get technical support information, software updates and fixes, and more. To connect to the IBBS: 1.

  • Page 12: Faxlink

    In the United States, call 1-800-633-7248 between the hours of 7:00 a.m. and 7:00 p.m. Central Time, Monday through Friday (except holidays). Outside the United States, contact your local Intergraph Computer Systems subsidiary or distributor. Have the following information available when you call: Your service number, which identifies your site to Intergraph Computer Systems.

  • Page 13: More Support Options

    Visit the Support pages on the World Wide Web at http://www.intergraph.com/ics. For hardware support questions in the United States, call 1-800-763-0242. For software support questions in the United States, call 1-800-345-4856. Outside the United States, contact your local Intergraph Computer Systems subsidiary or distributor.

  • Page 15: Setting Up The Hardware

    Setting Up the Hardware Follow the instructions in this chapter to set up the hardware for your TDZ 2000 GL1 or ExtremeZ GL1 workstation. NOTE If you have an ExtremeZ workstation, see the ExtremeZ Customer Welcome Letter first. The ExtremeZ Customer Welcome Letter provides step-by-step instructions for initial setup of an ExtremeZ workstation.

  • Page 16: Unpacking The System

    A monitor with video cable, power cord, and documentation (if purchased from Intergraph Computer Systems) Workstation and power cord Keyboard and mouse Intergraph Computer Systems documentation Windows NT Workstation 4.0 or Windows 95 operating system software (CD-ROM and diskettes) and documentation NOTE If any of these items were not delivered, call the Customer Response Center immediately at 1-800-633-7248.

  • Page 17: Setting Up The System

    CAUTION Do not move the system without first shutting down the system and turning off the power, or damage to internal components may result. Setting Up the System Before you connect any cables to the back of the system, note the connector locations in the following illustration.
  • Page 18 Video Out port on video display adapter card WARNING If you do not use cables supplied by Intergraph Computer Systems, you must use shielded cables to prevent excessive electromagnetic interference (EMI). Intergraph Computer Systems cables are designed to reduce the amount of EMI produced by the system.

  • Page 19: Installing Expansion Cards

    Expansion cards are installed in the Peripheral Component Interconnect (PCI) and Industry Standard Architecture (ISA) expansion slots in the base unit. If you purchased expansion cards from Intergraph Computer Systems, they are installed in specific slots as follows. Slot Type...

  • Page 20: Connecting An External Scsi Device

    then to a grounded, three-prong AC wall outlet. See the audio card documentation delivered with the system for more detailed connection information. If the system includes a multimedia keyboard, see the multimedia keyboard documentation delivered with the system for connection information. After you start the system for the first time, you may want to change the microphone’s BIAS setting to ensure the microphone works properly with the system.

  • Page 21: What's Next

    What’s Next? Intergraph Computer Systems installs the operating system through Phase I of the process. From here, continue the installation. See Chapter 2, “Setting Up the Software,” for instructions on setting up the operating system and associated system software.

  • Page 23: Setting Up The Software

    Setting Up the Software Follow the instructions in this chapter to set up the operating system and associated system software on your TDZ 2000 GL1 or ExtremeZ GL1 workstation. NOTE If you are setting up an ExtremeZ workstation for the first time, see the ExtremeZ Customer Welcome Letter .

  • Page 24: Preparing For Setup

    InterSite software Before You Start Setup Intergraph Computer Systems installs the operating system through Phase I of the process. You must follow the operating system Setup process to prepare Microsoft Windows NT or Microsoft Windows 95 for use. Before you go through Setup, have the following documents available: Microsoft’s Start Here (for Windows NT) or Welcome to Windows 95.
  • Page 25 Get and record the following information: Your name, and the name of your company or organization: For a system running Windows NT, the CD key from the Windows NT CD case, or the Product ID Number from Start Here or the registration card: For a system running Windows 95, the Product ID Number from Welcome to Windows 95 or the registration card:...

  • Page 26: Starting Operating System Setup

    Have several blank, formatted diskettes available to create backup diskettes containing drivers and system software. The Windows NT delivery media contain software and drivers for both Reduced Instruction Set Computing (RISC)- and Intel-based systems. When installing Windows NT distribution files, make sure you install them from the \ 386 directory (the Intel software directory) on the delivery media.

  • Page 27: Finishing System Setup

    On a system running Windows NT: On a system shipped from the factory without a CD-ROM drive, the system’s hard disk drive contains Windows NT Setup files in the directory. When installing network or video display adapter drivers, you can see the i directory when prompted for the location of Windows NT Setup files.

  • Page 28: Creating A Repair Disk

    CD-ROM or on backup diskettes delivered with expansion cards. See Version Manager Help for information on creating system software backup diskettes. Visit the Intergraph Computer Systems site on the World Wide Web and vendor bulletin boards for new and updated drivers.

  • Page 29: What's Next

    What’s Next? See the online System Introduction for information on system features and controls. See Chapter 3, “Configuring the System,” for information on configuring the system for use.

  • Page 31: Configuring The System

    Configuring the System Follow the instructions in this chapter to configure your TDZ 2000 GL1 or ExtremeZ GL1 workstation for use. This chapter covers items required for basic operation. Configuring the Video Display Driver................18 OpenGL Performance and Custom Cursors (Windows NT) ........19 Multiple Screen Display (Windows NT)...............

  • Page 32: Configuring The Video Display Driver

    Configuring the Video Display Driver The first time you start the system, your monitor displays at 1024 x 768 screen resolution. For the system to use the installed video adapter at other display resolutions, you must configure the video display driver as described in this section. Open Display in the Control Panel to configure the video display driver.

  • Page 33: Opengl Performance And Custom Cursors (Windows Nt)

    If you use a custom cursor while running an OpenGL program, performance may decrease whenever you position the cursor in that program’s window. For optimum performance of OpenGL programs, Intergraph Computer Systems recommends that you use only the standard cursors.

  • Page 34: Configuring Audio

    Screen option. A multi-sync monitor is selected, but a monitor with different video timings (such as an Intergraph InterVue monitor) is connected to the system. Select the appropriate monitor type as described previously. The monitor selection doesn’t match the multi-sync monitor attached to the system.
  • Page 35 Default Ensoniq Mixer Settings (Windows NT) If you need to return the Ensoniq mixer software to its default settings (for example, after reinstalling Windows NT), refer to the following illustration: Use these default mixer settings as a starting point to ensure proper system audio operation. You can then change the settings as needed to meet your recording and playback needs.
  • Page 36 Default Ensoniq Mixer Settings (Windows 95) If you need to return the Ensoniq mixer software to its default settings (for example, after reinstalling Windows 95), refer to the following illustration: Use these default mixer settings as a starting point to ensure proper system audio operation. You can then change the settings as needed to meet your recording and playback needs.

  • Page 37: Configuring Networking

    Configuring Networking If you purchased a network adapter with your system, it was installed before shipment. You must configure the operating system to use the network adapter. To do this, you may have to install network driver software and network adapter control software, and then change operating system settings to enable networking.

  • Page 38: Configuring A Tape Drive

    Configuring a Tape Drive If you purchased an internal tape drive with your system, it was installed before shipment. On a system running Windows 95, you may have to install the driver software and any associated applications software programs to use the tape drive. On a system running Windows NT, you can use the Windows NT Backup tool to run the tape drive;...

  • Page 39: Changing Hard Disk Drive Letters (Windows Nt)

    4. Set the remaining Onboard Serial Port parameter to Auto and restart the system, saving your changes. If configuring the modem under Windows NT, double-click the modem icon in Control Panel. Use the Install New Modem window to automatically detect the installed modem. Windows NT lists the name of the modem found.

  • Page 40: Changing Virtual Memory Settings (Windows Nt)

    Service Packs from the Microsoft World Wide Web and FTP sites free of charge. CAUTION If Intergraph Computer Systems provides a Service Pack through the IBBS or with a product or system, it has been certified against Intergraph Computer Systems hardware as described in the announcement of its availability.

  • Page 41: Configuring The Bios

    Configuring the BIOS This chapter describes how to use the AMIBIOS Setup program, and how to reprogram the system’s basic input/output system (BIOS) if needed. Use the information in this chapter if you want to configure aspects of system operation by changing the BIOS settings, or by updating the BIOS to take advantage of later enhancements.

  • Page 42: Overview

    Overview The system’s BIOS records basic system operating parameters, such as the amount of memory, the boot sequence, and the type of video display. The operating parameters are set in the BIOS before shipment. The BIOS is stored in flash erasable-programmable memory (EPROM) on the system board, and reads the system parameters in the system’s complementary metal-oxide semiconductor (CMOS) random-access memory (RAM).

  • Page 43: Bios Setup Menus

    BIOS Setup Menus The following sections detail the menus available from the BIOS Setup main menu. Standard Menu Select Standard in the BIOS Setup main menu to display the Standard Setup options. Pri Master, Pri Slave, Sec Master, Sec Slave Select these options to configure the primary (Pri) or secondary (Sec) drive named in the option.

  • Page 44: Advanced Menu

    Date/Time Select this option to display or change the current system date and time values. The time displays in 24-hour format. Floppy A, Floppy B Select these options to specify the type of floppy disk drive installed in the system. Floppy A is preset to 1.44 MB 3.5-inch.
  • Page 45 1st Boot Device This option sets the type of device for the first boot drive from which the BIOS attempts to boot after power-on self-test (POST) completes. The settings are Disabled, 1st IDE-HDD, 2nd IDE-HDD, 3rd IDE-HDD, 4th IDE-HDD, Floppy, ARMD-FDD, ARMD-HDD, ATAPI CDROM, SCSI, Network, and I2O.
  • Page 46 Primary Display This option configures the type of monitor attached to the system. The settings are Mono, CGA40x25, CGA80x25, VGA/EGA, or Absent. The Optimal and Fail-Safe settings are VGA/EGA. Password Check This option enables password checking every time the system boots or when you run BIOS Setup.

  • Page 47: Chipset Menu

    C000 16K Shadow, C400 16K Shadow These options specify how to use the 32 KB of video ROM at C0000h. The settings are: Setting Description Disabled The contents of the video ROM are not copied to RAM. Enabled The contents of the video ROM from C0000h - C7FFFh are copied (shadowed) from ROM to RAM for faster execution.
  • Page 48 DRAM Integrity Mode This option sets the type of system memory checking. The settings are: Setting Description Disabled No error checking or error reporting is done. Parity Multibit errors are detected and reported as parity errors. Single-bit errors are corrected by the chipset. Corrected bits of data from memory are not written back to DRAM system memory.
  • Page 49 VGA Frame Buffer USWC Set this option to Enabled to enable the VGA video frame buffer using USWC (Uncacheable, Speculatable, Write-Combined) memory. The settings are Enabled or Disabled. Older ISA VGA card drivers may not behave correctly if this option is not set to Disabled. The Optimal and Fail-Safe settings are Disabled.
  • Page 50 PCI Burst Write Combine Set this option to Enabled to enable PCI bus burst write operations to be combined. The settings are Enabled or Disabled. The Optimal and Fail-Safe settings are Enabled. Read Around Write Set this option to Enabled to enable read-around write operations. The settings are Enabled or Disabled.

  • Page 51: Power Management Menu

    Power Management Menu Select Power Management in the BIOS Setup main menu to display the Power Management Setup options. Power Management/APM Set this option to Enabled to enable the chipset power management and APM (Advanced Power Management) features. The settings are Enabled or Disabled. The Fail-Safe and Optimal settings are Disabled.
  • Page 52 Down Mode option. The settings are Disabled, 1 min. (minute), 2 min, 3 min., 4 min., 5 min., 6 min, 7 min., 8 min., 9 min., 10 min., 11 min., 12 min., 13 min., 14 min, and 15 min. The Optimal and Fail-Safe settings are Disabled. Standby Time Out (Minute) This option specifies the length of a period of system inactivity while in the Full On power state.

  • Page 53: Pci/Pnp Menu

    PCI/PnP Menu Select PCI/PnP in the BIOS Setup main menu to display the PCI/PnP Setup options. Plug and Play Aware Set this option to Yes to inform the BIOS that the operating system can handle plug and Play (PnP) devices. The settings are No or Yes. The Optimal and Fail-Safe settings are No. PCI Latency Timer (PCI Clocks) This option specifies the latency timings (in PCI clocks) for PCI devices installed in the PCI expansion slots.
  • Page 54 Offboard PCI IDE Card This option specifies if an off-board PCI IDE controller adapter card is used in the system. You must also specify the PCI expansion slot on the system board where the off-board PCI IDE controller card is installed. If an off-board PCI IDE controller is used, the system board’s on-board IDE controller is automatically disabled.

  • Page 55: Peripheral Menu

    C0000, C4000, C8000, CC000, D0000, D4000, D8000, or DC000. The Optimal and Fail- Safe default settings are C8000. Peripheral Menu Select Peripheral Setup from the BIOS Setup main menu to display the Peripheral Setup options. Onboard FDC Set this option to Enabled to enable the floppy disk drive controller on the system board. The settings are Auto (the BIOS automatically determines if the floppy disk drive controller should be enabled), Enabled, or Disabled.

  • Page 56: Security Menu

    Setting Description The parallel port can be used with devices that adhere to the Extended Capabilities Port (ECP) specification. ECP uses the DMA protocol to achieve data transfer rates up to 2.5 Megabits per second. ECP provides symmetric bi- directional communication. The Optimal and Fail-Safe settings are Normal.

  • Page 57: Utility Menu

    Anti-Virus The Anti-Virus setting is only relevant for floppy diskettes. Hard disk drives are not checked by this option. When Anti-Virus is Enabled, diskettes cannot be formatted unless a quick format is executed, which does not write to Track 0 on the diskette. A format that writes to Track 0 will not be performed.

  • Page 58: Reprogramming The Bios

    If so, after reprogramming the BIOS, you must run the BIOS Setup program and reallocate the system resources as needed. The FPU is available from the Support pages on the Intergraph Computer Systems World Wide Web site and from the Intergraph Bulletin Board Service (IBBS). Look for the system software product for TDZ 2000 GL1 or ExtremeZ GL1 systems.

  • Page 59: Assigning System Resources For Option Cards

    3. Use an unzip utility to open and extract the files from it. FLASHUTIL 4. Insert a blank, formatted diskette into the system’s floppy disk drive. 5. In the directory containing the files, run . This creates a boot FLASHUTIL INSTALL diskette with the new BIOS file and the BIOS flash programming utility.

  • Page 60: Summary Of Default Settings

    Summary of Default Settings The following sections list the default Optimal and Fail-Safe settings for the various BIOS parameters. N/A indicates that an Optimal or Fail-Safe setting is not available. Standard Menu Parameter Optimal Fail-Safe Pri Master Auto Auto Pri Slave Auto Auto Sec Master...

  • Page 61: Chipset Menu

    Chipset Menu Parameter Optimal Fail-Safe DRAM Speed (ns) DRAM Integrity Mode Disabled Disabled DRAM Fast Leadoff Enabled Enabled DRAM Refresh Type CAS/RAS CAS/RAS DRAM Refresh Queue Enabled Enabled VGA Frame Buffer USWC Disabled Disabled PCI Frame Buffer USWC Disabled Disabled Fixed Memory Hole Disabled Disabled...

  • Page 62: Pci/Pnp Menu

    Parameter Optimal Fail-Safe Display Activity Ignore Ignore IRQ# (3, 4, 5, 7, 9, 10, 11, 13, 15) Ignore Ignore IRQ# (12, 14) Monitor Ignore PCI/PnP Menu Parameter Optimal Fail-Safe Plug and Play Aware PCI Latency Timer (PCI Clocks) PCI VGA Palette Snoop Disabled Disabled PCI IDE Bus Master...

  • Page 63: Utility Menu

    Utility Menu Parameter Optimal Fail-Safe Language English English Detect IDE Default Menu Parameter Optimal Fail-Safe Original Optimal Fail-safe...

  • Page 65: Operating Notes

    Operating Notes This chapter contains important, basic information on operating your TDZ 2000 GL1 or ExtremeZ GL1 workstation. See the online System Introduction for basic information on system features and functions. Moving the System ......................52 Opening and Closing the Door ................... 52 Starting and Shutting Down the System ................

  • Page 66: Moving The System

    Moving the System WARNING Do not use the bottom portion of the face panel or the lip at the top rear of the unit as a hand hold when moving the system. Equipment damage and personal injury can result. Do not lift here! Do not lift here!

  • Page 67: Starting And Shutting Down The System

    2. Lower the door until it stops and then press gently until the door clicks into the closed position. Push Back Swing Up Lift Here Starting and Shutting Down the System After you complete Setup and start the system for the first time, you can start and stop the system as needed.
  • Page 68 To log on to the operating system: 1. If the logon dialog does not display, press to display it. CTRL DELETE 2. Type a username and password into the appropriate boxes. 3. If appropriate, type a domain name. 4. Select OK or press ENTER To log off, restart, or shut down the operating system: 1.

  • Page 69: Observing Operating Precautions

    Observing Operating Precautions Observe the following precautions when operating the system: When restarting the system, use the operating system controls instead of turning the power switch off and on. Use the power switch only when instructed, or as the last alternative for restarting the system.

  • Page 70: Updating An Emergency Repair Disk Or A Startup Diskette

    Updating an Emergency Repair Disk or a Startup Diskette You may have created an Emergency Repair Disk (Windows NT) or a Startup diskette (Windows 95) during first-time startup, or through InterSite Welcome. If you did not, you should create the appropriate diskette after you finish configuring the system. If you did, you should update it any time you change the configuration of the system.

  • Page 71: Windows 95 Osr 2.5 And The Active Desktop

    5. Under Startup Type, select Boot; then select OK. 6. In the Devices dialog, select Close. Windows 95 OSR 2.5 and the Active Desktop If you purchased a system with Windows 95, it shipped with Windows 95 OEM Service Release 2.5 (Microsoft Windows 95 4.00.950 C). Windows 95 OSR 2.5 integrates Internet Explorer version 4.01 into the operating system.

  • Page 72: Booting From An External Scsi Disk Drive

    To display the audio system’s Mixer program, do one of the following: Click the speaker icon on the operating system taskbar. From the Start menu, select Programs/Accessories/Multimedia/Volume Control. If you reinstall the operating system, or install a system audio option on a system that did not have it previously, you can set up the quick access feature yourself.

  • Page 73: Using Hardware Security Features

    To boot from an external SCSI disk drive: 1. Disconnect any IDE or EIDE disk drives from the primary and secondary IDE controllers. The system’s BIOS will not accept a mixture of SCSI and IDE/EIDE devices if the boot device is a SCSI disk drive. 2.

  • Page 75: Troubleshooting

    Troubleshooting Use this chapter to help identify the causes of problems that may occur on a TDZ 2000 GL1 or ExtremeZ GL1 workstation. See the System Reference for information on opening the case and working with internal components. If you cannot resolve the problem or if the instructions direct you to call the Customer Response Center, contact Intergraph Computer Systems.

  • Page 76: System Power

    System Power ERROR - Fails to power on. Reason Solution Power cord not connected properly. Verify that the power cord is properly connected to the power receptacle. Power not available at the outlet. Verify power to the outlet has not been interrupted.
  • Page 77 ERROR - Does not boot from the expected boot device. Reason Solution Boot sequence not correctly set. Change the boot sequence. See Chapter 4. Operating system not on the system drive. Install the operating system as described in Chapter 7. ERROR - Series of beeps and error message displays.
  • Page 78 ERROR - CD-ROM drive is not recognized. Reason Solution CD-ROM drive power cable not attached. Open case and ensure power cable is properly attached. See System Reference. CD-ROM drive cable not attached. Open case and ensure cable is properly attached. See System Reference. ERROR - System hard disk drive not recognized.

  • Page 79: Sound

    ERROR - Total amount of memory does not display. Reason Solution Faulty SIMM(s). Identify faulty SIMM(s) by swapping SIMM(s) until the faulty one is found. See System Reference. SIMM(s) not properly seated into socket(s). Ensure SIMM(s) are properly installed. See System Reference.

  • Page 80: Video

    Video ERROR - System powered on, but screen remains blank. Reason Solution Monitor not powered on. Turn on power to the monitor. Monitor power cord not connected. Connect monitor power cord to AC outlet and monitor. Video cable not properly installed. Ensure video cable is connected to monitor and case.

  • Page 81: Network

    Network ERROR - Cannot connect to other systems on LAN. Reason Solution Network cable disconnected. Reconnect network cable and ensure proper connection. If cable is properly connected, notify your System Administrator. Incorrect software configuration. Notify your System Administrator. ERROR - Cannot plot to network plotter on LAN. Reason Solution Network cable disconnected.

  • Page 83: Installing System Software

    Follow the instructions in this chapter if you need to reinstall the operating system and associated system software on your TDZ 2000 GL1 or ExtremeZ GL1 workstation. Before you reinstall the software, ensure that you read and understand this entire chapter.

  • Page 84: Before You Begin

    You can find the system software on backup diskettes that you created, on diskettes provided by Intergraph Computer Systems, or on the operating system CD-ROM. If you did not create backup diskettes of drivers or other system software products, they are probably available on the operating system CD-ROM or on backup diskettes delivered with expansion cards.
  • Page 85 Description Windows NT 4.0 Windows 95 IBBS Accel Graphics AccelSTAR II ACCEL2DRVNT ACCEL2DRV95 video driver Matrox Millennium II MILL2DRVNT MILL2DRVW95 video driver Intense 3D Pro 2200 video INTENSEDRV driver Ensoniq AudioPCI audio card ENSONIQDRV ENSONIQW95DR driver Primax mouse driver PMOUSE IKON PCI driver IKONPCIDRV 3COM 3C900 network adapter...

  • Page 86: Drivers And Applications For Extremez Systems

    Drivers and Applications for ExtremeZ Systems If you have an ExtremeZ system, it was shipped with the Drivers and Applications product on the Connectivity Plus CD-ROM. Drivers and Applications is a set of system drivers and applications specifically for rebuilding an ExtremeZ workstation. When this document instructs you to install a driver from backup diskette, use the Connectivity Plus CD-ROM instead, and type the path name for the driver as follows: drive:\drivers and apps\directory...

  • Page 87: Installing Windows Nt Workstation 4.0

    Installing Windows NT Workstation 4.0 Depending on your system’s configuration, you will need some or all of the following system software during the installation process: SCSI adapter driver Video display adapter driver Network adapter driver Sound adapter driver QFE update software Follow the instructions in Start Here to install Windows NT.

  • Page 88: Installing The Ensoniq Sound Adapter Driver

    If your system was running Windows NT 4.0 Service Pack software, install this software after installing drivers and other system software, and after installing any application software products. Perform any operational changes required for your system as described in Chapter 4, “Operating Notes.”...

  • Page 89: Disabling Command Queuing

    Disabling Command Queuing To improve standalone system performance and to improve performance with some high- performance SCSI peripherals, you should disable command queuing in the Windows NT Registry. WARNING Do not change values in the Registry other than as directed. If you introduce incorrect values into the Registry, you may cause serious operating system problems, and you may have to reinstall Windows NT.

  • Page 90: Installing Windows 95

    To enable IDE/ATAPI bus mastering: 1. Ensure that the operating system, Service Pack 3 software, and QFE update software ) are installed. NOTE The QFE update software includes an updated ATAPI device driver that should be installed after Service Pack 3. NOTE For reasons of system performance, if a TR-4i tape drive or a Zip drive is installed, do not enable DMA use on the IDE channel to which the drive is connected.
  • Page 91 2. Insert the Windows 95 CD-ROM in the CD-ROM drive. 3. Start (or restart) the system. 4. At the Windows 95 Startup Menu, select the option to install Windows 95. If you are installing Windows 95 on a system on which another operating system or a previous version of Windows 95 exists, you may have to partition and format the system’s hard disk before installing Windows 95.

  • Page 92: Installing The Ensoniq Sound Adapter Driver

    Configure the system as described in Chapter 3, “Configuring the System.” Perform any operational changes required for your system as described in Chapter 4, “Operating Notes.” You can install MS-DOS Microstation drivers, available from the Intergraph Bulletin Board Service (IBBS). Installing the Ensoniq Sound Adapter Driver Systems with an audio option include an Ensoniq sound card.

  • Page 93: Enabling Bus Mastering For Ide/Atapi Devices

    CAUTION If Intergraph provides a Service Pack or Service Release through the IBBS or with a product or system, it has been certified against Intergraph hardware as described in the announcement of its availability. If you obtain a Service Pack or Service Release from any...

  • Page 95: Using System Resources

    The chapter covers specific Peripheral Component Interconnect (PCI) and Industry Standard Architecture (ISA) devices offered by Intergraph as system options. Intergraph Computer Systems has determined that the devices discussed in this chapter require specific resource settings to ensure proper system operation.

  • Page 96: System Resources

    System Resources The following sections list the available system resources. See the vendor documentation delivered with an expansion card or a peripheral device for instructions on how to use these resources. ISA Bus Interrupt (IRQ) Assignments System Resource System Resource Reserved (interval timer) Real time clock Reserved (keyboard)
  • Page 97 Address (hex) Description 0094-009F Direct memory access controller 00A0-00A1 Programmable interrupt controller 00C0-00DE Direct memory access controller 00F0-00FF Numeric data processor 0170-0177 Tyan 32-Bit PCI EIDE bus master driver 0170-0177 Secondary PCI bus master EIDE driver (dual FIFO) 01F0-01F7 Tyan 32-Bit PCI EIDE bus master driver 01F0-01F7 Primary PCI bus master EIDE driver (dual FIFO) 0295-0296...

  • Page 98: Memory Addresses

    Memory Addresses Address Range (hex) Size Assignment 00000000-0009FBFF 640 KB System board extension for PnP BIOS 0009FC00-0009FFFF 1 KB System board extension for PnP BIOS 000A0000-000AFFFF 64 KB Cirrus Logic 5430/40 PCI 000B0000-000BFFFF 64 KB Cirrus Logic 5430/40 PCI 000C0000-000C7FFF 32 KB Unavailable for use by devices 000E0000-000FFFFF...

  • Page 99: Pci Devices

    The following expansion cards require specific system resource settings, as noted: Expansion card Resources BIOS Setup (installed in the system) required parameter settings First modem (Windows NT) COM3, IRQ 4 Disable serial port 1 (COM1); reserve IRQ 4 Second modem (Windows NT) COM2, IRQ 3 Disable serial port 2 (COM2);...
  • Page 100 2. Select Configure/View Host Adapter Settings. 3. Select Advanced Configuration Options. 4. Select Support for Ultra SCSI Speed. 5. Change the value Disabled to Enabled. 6. Press twice to exit the SCSISelect Utility. 7. In the Save Changes Made dialog, select Yes. 8.

  • Page 101: Index

    Index booting from an external SCSI disk drive, 58 bus mastering for IDE/ATAPI AC voltage switch devices setting, 5 enabling, 75, 79 AMIBIOS Security Menu, 42 Anti-Virus, 43 Supervisor, User, 42 CD recorder drive Setup configuring, 23 Help Screen, 28 Changing starting, 28 BIOS password, 42...
  • Page 102 62 Windows NT, 73 video, 66 installing Windows 95 with EULA (Microsoft End User installed network adapter, 78 License Agreement), 12 Intergraph expansion cards, 5 BBS, xi External SCSI device InterSite programs, 55 installing, 6 DMI Console, 55...
  • Page 103 Microsoft End User License assigning system resources, 45 Agreement (EULA), 12 PCI devices, 85 Miscellaneous hardware PCI expansion cards errors, 66 slots for, 5 mixer PCMCIA audio system, 57 operation, 56 Model number location, 60 support, 56 MS-DOS Placing system components, 2 starting, 54 precautions Multiple screen display, 19...
  • Page 104 hard disk drive letters, 25 system resources, 84 virtual memory, 26 system software Setup backup diskettes, 14 finishing system setup, 13 Quick-Fix Engineering (QFE) preparing for, 10 updates, 14 Welcome, 13 Setup files Windows 95, 13, 78 tape drive Windows NT, 13 configuring, 24 Setup files (Windows 95), 13 troubleshooting, 61...
  • Page 105 Version Manager, 14 installing, 73 Windows 95 PC Card operation, 56 boot diskette, 13, 76, 77 Setup files, 13 installing, 76 Setup files, 13, 78 Startup Diskette, 56 Zip drive Windows NT configuring, 23 Emergency Repair Disk, 56...

  • Page 107: Returned Goods Authorization (Rga) Form

    Mail Address Reason for Return NOTE All returned equipment MUST be shipped in original Intergraph packaging to obtain warranty service. WARNING Back up disk drives before returning equipment. Intergraph is not responsible for data lost in shipping or repair process.

  • Page 108: Warranty Procedure

    Warranty Procedure Some malfunctioning equipment cannot be repaired in the field, and you must return it to Intergraph for repair. Follow these steps to obtain a Returned Goods Authorization (RGA) log number and return the malfunctioning equipment. 1. Determine the serial number of the system. The serial number is located on the white bar code identification label on the back of the base unit.
  • Page 109 Repair Depot RGA No. ________________________ Intergraph Corporation 9805 Kellner Road Huntsville AL 35894 Repair Depot RGA No. ________________________ Intergraph Corporation 9805 Kellner Road Huntsville AL 35894 Repair Depot RGA No. ________________________ Intergraph Corporation 9805 Kellner Road Huntsville AL 35894...
