Wall Mounting the Spectrum PLUS
The Spectrum PLUS
conveniently wall
additional hardware.
Follow these easy steps:
1.The handset retaining clip must be in the correct
position to secure the handset into the handset
cradle. Engage the clip with your fingers and pull
the clip forward (towards you), rotate the clip 180º
and snap the clip back into place (figure 1). The
retaining clip cannot be removed.
2. The Spectrum PLUS
mounting wedge that must be correctly positioned.
This wedge allows the telephone to be viewed at a
correct angle when the phone is wall mounted.
Remove the wedge from the phone base (figure 2).
3. Secure the line cord, coil cord and any wiring in
place prior to installing the wall mount wedge. The
wall mount base has extra large wiring channels
and strain relief poles for containing the wires in a
neat and orderly way. Wrap the wires around the
strain relief poles and then
through the channel.
4. To wall mount, place the narrow edge at the top
edge of the phone base and slide the wedge up-
ward into place (figure 3).
5. Lock the wall mount into position by sliding the
locking button to the right (figure 4).
Note: A 6-inch line cord is provided for when
the telephone is to be wall mounted. Connect
one end of the line cord to the phone jack and
the other end to the wall jack. Be sure to con-
nect and line cord before placing mounting
!
wedge on the bottom base.
Desk Mounting
To install the wedge for desk mounting, be sure the lock mechanism is positioned to the left
clear of the locking arm. Place the wedge in the slots, wide end toward top of phone base
unit, and slide the wedge upward into position. Lock the wedge into place.
TM
was designed
mounted without
TM
has provisions for a
secure the wires
to be
requiring
1.
2.
3.
1.LIFT CLIP OUT WITH
FINGERS. IT CANNOT BE
REMOVED BECAUSE IT
IS SPRING LOADED.
2. ROTATE THE
0
CLIP 180 AND
IT WILL SMAP
BACK INTO THE OPPO-
SITE POSITION. AN
Replace Mounting Wedge
Replace Mounting Wedge
Lock Mounting Wedge
12
TM Telephone
RETAINER CLIP
NOTE: CLIP IS
UNS NA P
RO TA T E 1 80 .
SN AP I NT O P LA CE.
figure 1
figure 2
figure3
figure 4
